220016IX2S [Microchip]

The Adaptec® SmartRAID 2200 family is the industry's most versatile, fully featured and secure full RAID enabled Tri-Mode SAS/SATA/NVMe server storage performance solution for server OEM, storage systems, data center and enterprise customers. The SmartHBA 2200 PCIe Gen 4 to Tri-mode host bus adapter is performance optimized for the lowest possible cost.

Built on Microchip's proven 5th generation storage controller, the SmartIOC 2200, the SmartHBA 2200 product sup- ports a x8 PCIe Gen 4 host interface with 16 media facing port variants for internal Tri-mode connectivity. The Smart- HBA 2200 is specifically designed for the most demanding NVMe and multi-port SAS SSD applications. The SmartIOC 2200 integrated PCIe Switch enables DirectPath technology - the industry's lowest latency and high bandwidth NVMe solution and the flexibility to support x1, x2, x4, and x8 wide NVMe SSDs.

This industry first 24G SAS adapter supports SAS-4 connec- tivity as well as Microchip's Dynamic Channel Multiplexing (DCM) technology that aggregates expander attached SAS or SATA hard drives onto 24G SAS infrastructure with near 100% link efficiency for unparalleled throughput. Native HBA modes for all media types are also supported, which offers the lowest latency for memory-based PCIe storage. Superior performance enables the SmartHBA 2200 to reach up to 13 GB/s throughput and 3.5M+ IOPs 4K random reads.

Microchip’s Trusted Platform support delivers a new level of compute and supply chain security based on a hard- ware root of trust that is aligned with the Open Compute Security Project.
