    AC244054 [Microchip]

    AC244054
    AC244054

    Part No:

    AC244054

    Category:

    Unclassified

    Manufacturer:

    Microchip

    Description:

    14/20-Pin, 8-Bit Flash USB Microcontroller with XLP Technology, featuring High-Performance RISC CPU and Extreme Low-Power Management.

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    TypeParameter
    Data Memory
    1024 bytes
    Operating Current
    25µA/MHz @ 1.8V (typical)
    Operating Voltage Lf
    1.8V to 3.6V
    Operating Voltage Non Lf
    2.3V to 5.5V
    PIC16(L)F1454 Adc
    none
    PIC16(L)F1454 Comparators
    0
    PIC16(L)F1454 Cwg
    none
    PIC16(L)F1454 Io
    11
    PIC16(L)F1455 Adc
    5 channels
    PIC16(L)F1455 Comparators
    2
    PIC16(L)F1455 Cwg
    1
    PIC16(L)F1455 Io
    11
    PIC16(L)F1459 Adc
    9 channels
    PIC16(L)F1459 Comparators
    2
    PIC16(L)F1459 Cwg
    1
    PIC16(L)F1459 Io
    17
    Package
    PDIP, SOIC, TSSOP, QFN/UQFN (4x4)
    Program Memory
    14 Kbytes (8192 words)
    Sleep Current
    25nA @ 1.8V (typical)
    Timer1 Oscillator Current
    600nA @ 32kHz (typical)
    Watchdog Current
    290nA @ 1.8V (typical)

    Products Detail

    The PIC16(L)F145X family combines a high-performance RISC CPU with extreme low-power management and integrated USB functionality. It features 14 Kbytes of program memory, 1024 bytes of data memory, and operates at speeds up to 48 MHz with an 83 ns instruction cycle. Key capabilities include a flexible oscillator structure with a 16 MHz internal oscillator (±0.25% accuracy), USB 2.0 compliance supporting low/full speeds (1.5/12 Mb/s), and comprehensive analog features including a 10-bit ADC (up to 9 channels), two comparators, and a 5-bit DAC. Peripheral highlights include multiple timers, two 10-bit PWM modules, a Complementary Waveform Generator (on select models), MSSP (SPI/I2C), and EUSART. Special features include self-programmable Flash, power-on/brown-out resets, extended watchdog timer, and in-circuit serial programming. The XLP technology enables ultra-low sleep currents (25nA typical).

    Key Features

    • High-Performance RISC CPU: 49 instructions, 14 Kbytes program memory, 1024 bytes data memory, 48 MHz operation. Low-Power Management: Sleep mode 25nA @ 1.8V, Watchdog 290nA, Operating Current 25 μA/MHz. Flexible Oscillator: 16 MHz internal oscillator (±0.25%), 31 kHz low-power oscillator, clock switching. USB Features: USB 2.0 compliant, self-tuning, low/full speed, 8 endpoints. Analog Features: 10-bit ADC (9 external channels), two comparators, voltage reference, 5-bit DAC. Peripherals: Timers (8/16-bit), PWM (2x 10-bit), CWG, MSSP (SPI/I2C), EUSART (RS-232/485/LIN), Interrupt-on-Change. Special Features: Power-on/Brown-out reset, watchdog timer, code protection, ICSP.

    Documents

    Datasheets:

    PIC16(L)F1454,5,9 Datasheet

    ConflictMineralStatement:

    Microchip-company-68.pdf
    Product FAQ

    1. Is AC244054 available for RFQ?

    Yes. AC244054 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for AC244054?

    Pricing for AC244054 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of AC244054?

    AC244054 is a Microchip Unclassified with PIC16(L)F1454 Comparators: 0 and PIC16(L)F1455 Comparators: 2. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for AC244054?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can AC244054 be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to AC244054?

    Yes. If AC244054 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Unclassified parts or compatible alternatives.
