APTDF400AK60G [Microchip]

Name: APTDF400AK60G
Brand: Microchip
SKU: APTDF400AK60G
Availability: InStock

Part No:

APTDF400AK60G

Category:

Power Supplies

Manufacturer:

Microchip

Description:

600V, 400A diode phase leg power module with ultra fast recovery characteristics.

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Isolation Voltage

4000V

Storage Temperature

-40°C ~ 125°C

Weight

300 g

RoHS Status

RoHS Compliant

RoHS Status

RoHS Compliant

Package

SP6

Forward Current Avg Max

400A

Forward Current Avg Max 25C

500A

Forward Current Rms

500A

Forward Surge Current

3000A

Forward Voltage

2.0V

Junction Capacitance

760pF

Mounting Torque Heatsink Max

5 N.m

Mounting Torque Heatsink Min

3 N.m

Mounting Torque Terminals Max

3.5 N.m

Mounting Torque Terminals Min

2 N.m

Operating Temperature Case Max

100°C

Operating Temperature Case Min

-40°C

Operating Temperature Junction Max

175°C

Operating Temperature Junction Min

-40°C

Reverse Leakage Current 25C

750µA

Reverse Recovery Charge

1.16 µC

Reverse Recovery Current

20A

Reverse Recovery Time

160 ns

Reverse Voltage

600V

Thermal Resistance Jc

0.14°C/W

Products Detail

Ultra fast recovery diode module featuring high blocking voltage (600V), high current (400A @ Tc=80°C), soft recovery characteristics, and very low stray inductance. Includes symmetrical design, M5 power connectors, and high integration. Benefits include outstanding high-frequency performance, low losses, low noise switching, direct mounting to heatsink (isolated package), low junction-to-case thermal resistance, and RoHS compliance.

Key Features

Ultra fast recovery times, Soft recovery characteristics, High blocking voltage, High current, Low leakage current, Very low stray inductance, Symmetrical design, M5 power connectors, High level of integration, Outstanding performance at high frequency operation, Low losses, Low noise switching, Direct mounting to heatsink (isolated package), Low junction to case thermal resistance, RoHS Compliant

Application scenarios

Anti-Parallel diode
Uninterruptible Power Supply (UPS)
Induction heating
Welding equipment
High speed rectifiers

Documents

Datasheets:

APTDF400AK60G Power Products Catalog

Product FAQ

1. Is APTDF400AK60G available for RFQ?

Yes. APTDF400AK60G by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for APTDF400AK60G?

Pricing for APTDF400AK60G can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of APTDF400AK60G?

APTDF400AK60G is a Microchip Power Supplies with Operating Temperature Junction Max: 175°C and Operating Temperature Junction Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for APTDF400AK60G?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can APTDF400AK60G be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to APTDF400AK60G?

Yes. If APTDF400AK60G is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Power Supplies parts or compatible alternatives.
