MIC38C44ABMM [Microchip]

Name: MIC38C44ABMM
Brand: Microchip
SKU: MIC38C44ABMM
Availability: InStock

Part No:

MIC38C44ABMM

Category:

Power Supplies

Manufacturer:

Microchip

Description:

BiCMOS Current-Mode PWM Controllers

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Package

8-Lead SOIC (M) and 8-Lead MSOP (MM)

MIC38C42A Max Duty Cycle Max

96%

MIC38C42A Max Duty Cycle Min

94%

MIC38C42A Min Operating Voltage Max

10V

MIC38C42A Min Operating Voltage Min

8V

MIC38C42A Start Threshold Max

15.5V

MIC38C42A Start Threshold Min

13.5V

MIC38C43A Max Duty Cycle Max

96%

MIC38C43A Max Duty Cycle Min

94%

MIC38C43A Min Operating Voltage Max

8.2V

MIC38C43A Min Operating Voltage Min

7.0V

MIC38C43A Start Threshold Max

9.0V

MIC38C43A Start Threshold Min

7.8V

MIC38C44A Max Duty Cycle Max

50%

MIC38C44A Max Duty Cycle Min

46%

MIC38C44A Min Operating Voltage Max

10V

MIC38C44A Min Operating Voltage Min

8V

MIC38C44A Start Threshold Max

15.5V

MIC38C44A Start Threshold Min

13.5V

MIC38C45A Max Duty Cycle Max

50%

MIC38C45A Max Duty Cycle Min

46%

MIC38C45A Min Operating Voltage Max

8.2V

MIC38C45A Min Operating Voltage Min

7.0V

MIC38C45A Start Threshold Max

9.0V

MIC38C45A Start Threshold Min

7.8V

Max Operation Frequency

500kHz

Operating Ambient Temperature

-40°C ~ +85°C

Operating Supply Current

4.0mA

Reference Voltage

5.00V

Start Up Current

100µA

Thermal Resistance Msop8

250°C/W

Thermal Resistance Soic8

170°C/W

Products Detail

The MIC38C4xA are fixed-frequency, high-performance, current-mode PWM controllers with BiCMOS process. They are pin compatible with UC384x series, featuring ultra-low start-up current (100μA typical), low quiescent operating current (4mA typical), CMOS outputs with rail-to-rail swing, up to 500kHz current-mode operation, trimmed 5V bandgap reference, and UVLO with hysteresis. Available in 8-pin SOIC and MSOP-8 packages.

Key Features

Fast 40ns Output Rise and 30ns Output Fall Times
–40°C to +85°C Ambient Temperature Range
High-Performance, Low-Power BiCMOS Process
Ultra-Low Start-Up Current (100μA Typical)
Low Quiescent Operating Current (4mA Typical)
CMOS Outputs with Rail-to-Rail Swing
Up to 500kHz Current-Mode Operation
Trimmed 5V Bandgap Reference
Pin-for-Pin Compatible with UC3842/3843/3844/3845
Trimmed Oscillator Discharge Current
UVLO with Hysteresis
Low Cross-Conduction Currents

Application scenarios

Current-Mode
Offline
Switched-Mode Power Supplies
Current-Mode
DC-to-DC Converters
Step-Down Buck Regulators
Step-Up Boost Regulators
Flyback
Isolated Regulators
Forward Converters
Synchronous FET Converters
