MICRF229YQS [Microchip]

The MICRF229 is a 400MHz to 450MHz super-heterodyne, image-reject, RF receiver with automatic gain control, ASK/OOK demodulator, and analog RSSI output. It only requires a crystal and a minimum number of external components to implement. The MICRF229 is ideal for low-cost, low-power, RKE, TPMS, and remote actuation applications.

The MICRF229 achieves -112dBm sensitivity at a bit rate of 1kbps with 1% BER. Eight demodulator filter bandwidths are selectable in binary steps from 1625Hz to 34kHz at 433.92MHz, allowing the device to support bit rates up to 20kbps. The device operates from a supply voltage of 3.5V to 5.5V, and typically consumes 6.0mA at 433.92MHz. The MICRF229 has a shutdown mode and sleep mode that reduce current to 0.5μA and 15μA respectively.

• -112dBm sensitivity at 1kbps with 1% BER
• Auto-polling mode with bit checking
• Supports bit rates up to 20kbps at 433.92MHz
• 25dB image-reject mixer
• No IF filter required
• 60dB analog RSSI output range
• 3.5V to 5.5V supply voltage range
• 6.0mA supply current at 434MHz
• 15µA supply current in sleep mode
• 0.5µA supply current in shutdown mode
• 16-pin 4.9mm × 6.0mm QSOP package
• -40°C to +105°C temperature range
• 2kV HBM ESD rating
