    Part number
    Part number
    1. Home/
    2. All Categories/
    3. Wireless & RF Semiconductors/
    4. Wireless Modules/
    5. RN2903-I/RM095 Microchip

    RN2903-I/RM095 [Microchip]

    RN2903-I/RM095
    RN2903-I/RM095

    Part No:

    RN2903-I/RM095

    Category:

    Wireless Modules

    Manufacturer:

    Microchip

    Description:

    Microchip's RN2903 Low-Power Long Range LoRa Technology Transceiver module provides an easy to use, low-power solution for long range wireless data transmission.

    RoHS Status:

    Product FAQ

    1. Is RN2903-I/RM095 available for RFQ?

    Yes. RN2903-I/RM095 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for RN2903-I/RM095?

    Pricing for RN2903-I/RM095 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of RN2903-I/RM095?

    RN2903-I/RM095 is a Microchip Wireless Modules with Deep Sleep Current Typ: 0.0013mA and Operating Temperature: -40°C ~ +85°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for RN2903-I/RM095?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can RN2903-I/RM095 be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to RN2903-I/RM095?

    Yes. If RN2903-I/RM095 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Wireless Modules parts or compatible alternatives.

    RFQ

    Part Number:

    RN2903-I/RM095

    Manufacturer:

    Microchip

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Operating Temperature
    -40°C ~ +85°C
    Supply Voltage
    2.1V ~ 3.6V
    RoHS Status
    RoHS Compliant
    Dimensions
    17.8 x 26.7 x 3.34 mm
    Weight
    2.05g
    Storage Temperature
    -40°C ~ +115°C
    RoHS Status
    RoHS Compliant
    Data Rate Fsk Max
    300 kbps
    Data Rate Lora Max
    12500 bps
    Deep Sleep Current Typ
    0.0013mA
    Frequency Band Max
    928.000MHz
    Frequency Band Min
    902.000MHz
    Harmonics Level
    < -70 dBm
    Idle Current Typ
    2.8mA
    Interface
    UART
    Modulation
    FSK, GFSK, LoRa
    Operating Humidity
    10% ~ 90%
    Range Suburban Max
    15 km
    Range Urban Max
    5 km
    Rf Connection
    Board edge
    Sensitivity
    -146 dBm
    Transmit Current Typ
    121mA
    Tx Power Max
    +18.5 dBm

    Products Detail

    The RN2903 module is a low-power, long-range transceiver operating in the 915 MHz frequency band. It integrates RF, baseband controller, command API processor, and features an on-board LoRaWAN stack. It offers UART interface, 14 GPIOs, and is suitable for simple long-range sensor applications with an external host MCU. The module provides high receiver sensitivity (-146 dBm) and adjustable TX power up to +18.5 dBm, with coverage up to 15 km in suburban areas.

    Key Features

    • On-Board LoRaWAN™ Protocol Stack, ASCII Command Interface over UART, Compact Form Factor: 17.8 x 26.7 x 3.34 mm, Castellated SMT Pads for Easy and Reliable PCB Mounting, Environmentally Friendly, RoHS Compliant, Modular Certified for the United States (FCC) and Canada (IC), Device Firmware Upgrade (DFU) over UART, Single Operating Voltage: 2.1V to 3.6V (3.3V typical), Temperature Range: -40°C to +85°C, Low-Power Consumption, Programmable RF Communication Bit Rate up to 300 kbps with FSK Modulation, 12500 bps with LoRa® Technology Modulation, Integrated MCU, Crystal, EUI-64 Node Identity Serial EEPROM, Radio Transceiver with Analog Front End, Matching Circuitry, 14 GPIOs for Control and Status, Shared with 13 Analog Inputs, Low-Power Long Range Transceiver Operating in the 915 MHz Frequency Band, High Receiver Sensitivity: Down to -146 dBm, TX Power: Adjustable up to +18.5 dBm High Efficiency PA, FSK, GFSK, and LoRa Technology Modulation, Up to 15 km Coverage at Suburban and up to 5 km Coverage at Urban Area

    Application scenarios

    • Automated Meter Reading
    • Home and Building Automation
    • Wireless Alarm and Security Systems
    • Industrial Monitoring and Control
    • Machine to Machine (M2M)
    • Internet of Things (IoT)

    Documents

    Datasheets:

    RN2903 Datasheet

    ConflictMineralStatement:

    Microchip-company-68.pdf
