RNWF02PC-I/100 [Microchip]

RNWF02PC is a 2.4-GHz IEEE^® 802.11 b/g/n plug-and-play, Wi-Fi^® controller module with a PCB antenna and Trust&GO secure element. With its on-chip network stack, this module is easy to set up and connect to any cloud platform.

RNWF02 features include:

• Wi-Fi 6 compatible
• Send commands to any microcontroller (MCU) using simple ASCII commands over the UART interface
• Integrated power amplifier (PA) and TX/RX switch with power management
• Immutable secure boot with hardware root of trust
• Embedded TCP/IP stack along with IPv6 and WPA3 security
• Integrated Trust&GO secure element

Wi-Fi:
• 2.4 GHz IEEE 802.11 b/g/n Wi-Fi
• Compatible with Wi-Fi 6/7 2.4 GHz band
• Single spatial stream with 20 MHz channel bandwidth
• RF-ready with PCB antenna
• Soft-AP/STA mode
• Hardware-based IEEE 802.15.2 compliant three-wire PTA interface for Wi-Fi/Bluetooth® coexistence
• Over-the-air (OTA) firmware updates

Network and Cloud:
• Authentication to any cloud servers supporting MQTT
• Network features: TCP, UDP, DHCP, ARP, HTTP, MQTT, IPv4 and IPv6, TLS 1.2 and DNS, SNTP
• Wi-Fi provisioning TCP server

Security:
• WPA2 and WPA3 personal Wi-Fi security
• Immutable secure boot with hardware root of trust

Operating Conditions:
• Operating voltage: 3.0 to 3.6 V
• Operating temp: -40 to +85 ºC

Package:
• 28-Pin SMD with shield CAN
• Size: 21.7 x 14.7 x 2.1 mm

Certifications:
• Wi-Fi Alliance certified (WFA) device
• CE (EU)
• UKCA (UK)
• FCC (USA)
• ISEDC (Canada)
• JRF (Japan)
• KCC (South Korea)
• NCC (Taiwan)
• RoHs and REACH Compliant
