LNK563DN-TL [Power Integrations]

Name: LNK563DN-TL
Brand: Power Integrations
SKU: LNK563DN-TL
Availability: InStock

Part No:

LNK563DN-TL

Category:

Power Supplies

Manufacturer:

Power Integrations

Description:

7 Terminations AC to DC power converter LinkSwitch®-LP Series 83kHz Min 85V V Max 265V V

RoHS Status:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

4 Weeks

Mounting Type

Surface Mount

Package / Case

8-SOIC (0.154, 3.90mm Width), 7 Leads

Surface Mount

YES

Operating Temperature

-40°C~150°C TJ

Packaging

Tape & Reel (TR)

Series

LinkSwitch®-LP

Published

2007

JESD-609 Code

e3

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

7

ECCN Code

EAR99

Terminal Finish

Matte Tin (Sn)

Power (Watts)

2.5W

HTS Code

8542.39.00.01

Max Power Dissipation

2.5W

Terminal Position

DUAL

Terminal Form

GULL WING

Number of Functions

1

Terminal Pitch

1.27mm

Pin Count

8/7

JESD-30 Code

R-PDSO-G7

Analog IC - Other Type

SWITCHING REGULATOR

Topology

Flyback

Output Current-Max

0.2A

Frequency - Switching

83kHz

Control Technique

PULSE WIDTH MODULATION

Switcher Configuration

SINGLE

Internal Switch(s)

Yes

Fault Protection

Current Limiting, Open Loop, Over Temperature, Short Circuit

Max Duty Cycle

70 %

Max Supply Voltage (AC)

265V

Output Isolation

Isolated

Voltage - Breakdown

700V

Min Supply Voltage (AC)

85V

Length

4.9mm

Height Seated (Max)

1.75mm

Width

3.9mm

Radiation Hardening

No

RoHS Status

RoHS Compliant

Lead Free

Products Detail

LNK563DN-TL Overview

In the package 8-SOIC (0.154, 3.90mm Width), 7 Leads , the ac to dc converter is embedded.The AC/DC power converter type is Tape & Reel (TR) .It is mounted in the way of Surface Mount .For the ac dc converter to perform at its best, it should be operated at a temperature of -40°C~150°C TJ °C.Analog ICs of type SWITCHING REGULATOR are used in this AC DC converter.In this AC to DC transformer, the switching frequency is 83kHz .As a result, it has had 7 terminations.There are 8/7 pins in the ac-dc converter.It belongs to the family of LinkSwitch®-LP manufacturers.A maximum current of 0.2A may be supplied to the ac to dc inverter.Across the converter, the minimum supply voltage is 85V .A maximum voltage of 265V can be applied across the converter.
