TNY375DG [Power Integrations]

TinySwitch-PK incorporates a 700 V MOSFET, oscillator, high-voltage switched current source, current limit (user selectable), and thermal shutdown circuitry. It features a unique peak mode that boosts current limit and frequency for peak load conditions. The device uses simple ON/OFF control without loop compensation, offers selectable current limit through BP/M capacitor value, and provides self-biasing for TNY375-376. It includes frequency jittering to reduce EMI filter costs, optimized pinout for PCB design, and enhanced safety features like thermal shutdown, auto-restart, and output overvoltage shutdown. EcoSmart technology ensures high energy efficiency with low no-load power consumption.
