Name: DA9080-62FCB2
Brand: RENESAS
SKU: DA9080-62FCB2

DA9080-62FCB2 [RENESAS]

Part No:

DA9080-62FCB2

Buffer Modules

Manufacturer:

RENESAS

Description:

Highly Integrated PMIC with 4 Bucks, 1 LDO & 8-Bit ADC in a QFN Package

Package:

-

RoHS Status:

-

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Lead Count (#)

Moisture Sensitivity Level (MSL)

Qty. per Reel (#)

6000

Pb (Lead) Free

Yes

Temp. Range

-40 to +85°C

Advanced Features

8 bit ADC

Buck-Boost DC/DC Converter Channels (#)

Bus Voltage (Max) (V)

5.5

Comm. Interface

I2C

Device Functions

PMIC

Function

5-ch PMIC

GPIOs (#)

Input Voltage (Max) (V)

5.5

Input Voltage (Max) [Rail 1] (V)

5.5 - 5.5

Input Voltage (Max) [Rail 2] (V)

5.5 - 5.5

Input Voltage (Min) (V)

Input Voltage (Min) [Rail 1] (V)

Input Voltage (Min) [Rail 2] (V)

Input Voltage Range (V)

4 - 5.5

Integrated step-down DC/DC Converter Channels (#)

Interface

I2C

LDOs

Linear Output

MOQ

6000

Nominal VDD

4 to 5.5

Output Current (Max) [Rail 1] (A)

1.5

Output Current Max (A)

Output Voltage (Max) (V)

3.3

Output Voltage (Max) [Rail 1] (V)

3.3

Output Voltage (Min) (V)

0.8

Output Voltage (Min) [Rail 1] (V)

2.1

Outputs (#)

Package Area (mm²)

Parametric Category

Multi-Channel Power Management ICs (PMICs)

Pkg. Dimensions (mm)

5 x 5

Pkg. Type

QFN-32

Switching Regulators

VIN Range (V)

4.0 - 5.5

Moisture Sensitivity Level (MSL)

Pb (Lead) Free

Yes

ECCN (US)

EAR99

Products Detail

The DA9080 is a five-output configurable power management IC (PMIC) that has four synchronous step-down buck regulators and one 200mA LDO. One of the bucks is capable of up to 5A of output current. Robust protection features include undervoltage lockout (UVLO), overcurrent protection (OC), and thermal protection for fault protection features. The DA9080 is offered in a 32-lead QFN package.

Power supply voltage (V_IN) 4.0V to 5.5V
Selectable output voltage range for 4 bucks:
- CH1 Buck: 2.1V to 3.3V, 20mV step, 1.5A
- CH2 Buck: 1.5V to 2.6V, 20mV step, 1.5A
- CH3 Buck: 0.9V to 1.3V, 5mV step, 1.5A
- CH4 Buck: 0.8V to 1.4V, 5mV step, 5.0A
LDO:
- V_OUT: 3.3V
- I_OUT: 0.2A (max)
General-purpose ADC:
- 8-bit SAR ADC
- Two external inputs
- Die temperature sense
Protection functions:
- Overcurrent protection
- Overvoltage protection
- Undervoltage protection
- Thermal shutdown protection
I²C control interface:
- Standard mode (100kbit/s)
- Fast mode (400kbit/s)
- Fast mode+ (1Mbit/s)
Package: QFN32 5.0mm x 5.0mm
