RH4Z2501BJ3GNM#HD1 [RENESAS]

Name: RH4Z2501BJ3GNM#HD1
Brand: RENESAS
SKU: RH4Z2501BJ3GNM#HD1

Part No:

RH4Z2501BJ3GNM#HD1

Driver ICs

Manufacturer:

RENESAS

Description:

Single Channel IO-Link Physical Layer Transceiver with Enhanced Protection

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Pkg. Type

DFN

Lead Count (#)

Carrier Type

Reel

Moisture Sensitivity Level (MSL)

Internal TVS Surge Protection

Pitch (mm)

0.5

Pkg. Dimensions (mm)

3.0 x 3.0 x 0.75

Qty. per Reel (#)

1800

Pb (Lead) Free

Yes

Pb Free Category

e3 Sn

Temp. Range

-40 to 125°C

Country of Assembly

Thailand

Country of Wafer Fabrication

Germany

Advanced Features

Embedded reverse polarity, overvoltage, and surge protection

Channels (#)

Length (mm)

MOQ

1800

Qty. per Carrier (#)

Reel Size (in)

Supply Voltage (V)

9 - 36

Tape & Reel

Yes

Thickness (mm)

0.75

Width (mm)

Moisture Sensitivity Level (MSL)

Pb (Lead) Free

Yes

ECCN (US)

NLR

HTS (US)

8542390060

Products Detail

The RH4Z2501 is a line driver / level shifter IC for IO-link communication with integrated protection. It addresses the IO-Link device physical layer for sensors and actuator systems. Furthermore, the IC can also be used as single channel master. For device configuration and status reading, an OWI communication interface is available. The output drivers allow push-pull operation, with a maximum RDSon of less than 2.5Ω for all operational temperatures. The RH4Z2501 is fabricated in a powerful CMOS mixed-signal technology that allows short supply voltage peaks up to 60V.

Voltage supply range from 9V to 36V
Over-voltage peak robustness of ±60V
Ambient Temperature range -40°C to 125°C
Configurable driver output current 50mADC to 400mADC
RDSON of less than 2.5Ω
Adjustable driver slew rate
Integrated Wake-up detection
MCU assisted Wake-up generation (typ. 700mA)
OWI digital communication and calibration interface
Integrated Linear Voltage Regulators 3.3V and 5V
Glitch filter for receiver
Integrated protection:
- ±1.25kV/2.5A (peak) surge protection for L+, CQ, GND/L- (8/20 μs pulse acc. IEC 61000-4- 5)
- Reverse polarity protection for L+, CQ, GND/L-
On-chip diagnostics:
- Over temperature detection
- Supply voltage monitor
- Broken chip detection
