Name: SLG59M1748CTR
Brand: RENESAS
SKU: SLG59M1748CTR

SLG59M1748CTR [RENESAS]

Part No:

SLG59M1748CTR

Power Supplies

Manufacturer:

RENESAS

Description:

5V, 36mΩ, 2.2A Load Switch with Reverse Current Blocking

Package:

-

RoHS Status:

-

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Lead Count (#)

Temp. Range

-40 to +85°C

Current Monitor Output

Discharge Circuit

Enable

Active High

FET Pass Device Type

Single P-Channel

IDS (A)

2.2

IDS Channel 1 (A)

2.2

Internal TVS Surge Protection

Output Discharge Circuit

Output Voltage Slew Rate set by

Internally Fixed

Over Current Protection (OCP)

Over Temperature Protection (OTP)

Over Voltage Protection

Parametric Category

Load Switches

Pkg. Dimensions (mm)

0.8 x 0.8 mm

Pkg. Type

WLCSP-4

Power Good (PG), FAULT indicator

Power Monitor Output

Protection Features

RCB, RVD

Published

Yes

RDSON (Typ) (mΩ)

RDSON (Typ) Channel 1 (mΩ)

Ramp Control

Internally Fixed

Reverse current blocking

Yes

Reverse voltage detection

Yes

Short Circuit Protection

Undervoltage Protection

VD/VIN (Max)

VD/VIN (Min)

1.6

VIN Channel 1 max. (V)

VIN Channel 1 min. (V)

1.6

VIN Range (V)

1.6 - 5

VIN Range Channel 1 (V)

1.6 - 5

VIN max. (V)

VIN min. (V)

1.6

VOUT Discharge Circuit

Products Detail

Operating from a 1.6V to 5V power supply, the SLG59M1748C is a self‑powered, high‑performance, 36mΩ pFET load switch designed for high‑side power‑rail applications up to 2.2A. When ON, internal reverse‑current protection will quickly open the switch in the event of a reverse‑voltage condition is detected (a V_OUT > V_IN + 32mV condition opens the switch). When OFF, the pFET’s internal body diode is connected to the higher voltage of V_IN/V_OUT to prevent reverse‑path leakage current. The SLG59M1748C is an ideal pFET load switch in any application where two power sources are likely to be multiplexed to one output.

Low RDS_ON: 36mΩ
Continuous I_DS: Up to 2.2A
Wide Input Voltage Range: 1.6V ≤ V_IN ≤ 5.0V
Low Reverse-voltage Detection Threshold: 35mV
Reverse-current Blocking
- Bulk Switch to V_IN if V_IN > V_OUT; else to V_OUT
Operating Temperature Range: -40 °C to 85 °C
Pb-free/RoHS-compliant 4L WLCSP
- 0.8mm x 0.8mm x 0.5mm, 0.4mm pitch
Other Options Available via Metal Revision
- Integrated V_OUT Discharge Resistor Enabled
