BBD-112-G-C [Samtec]

Name: BBD-112-G-C
Brand: Samtec
SKU: BBD-112-G-C
Availability: InStock

Part No:

BBD-112-G-C

Category:

Headers & Wire Housings

Manufacturer:

Samtec

Description:

BBD Series 2-Row Header Solder Brass Tube Through Hole Gold Polyester, Glass Filled 24-Position Board to Board 0.585 14.86mm Height

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

3 Weeks

Contact Material

Brass

Mount

Through Hole

Mounting Type

Through Hole

Contact Shape

Circular

Insulation Material

Polyester, Glass Filled

Operating Temperature

-55°C~125°C

Packaging

Tube

Series

BBD

JESD-609 Code

e4

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Termination

Solder

Connector Type

Header

Number of Positions

24

Number of Rows

2

Gender

Male

Fastening Type

Push-Pull

Contact Finish - Mating

Gold

MIL Conformance

NO

DIN Conformance

NO

IEC Conformance

NO

Filter Feature

NO

Contact Type

Male Pin

Mixed Contacts

NO

Option

GENERAL PURPOSE

Insulation Height

0.585 14.86mm

Style

Board to Board

Number of Positions Loaded

All

Pitch - Mating

0.100 2.54mm

Insulation Color

Black

Number of Conductors

ONE

Reference Standard

UL

Reliability

COMMERCIAL

Row Spacing - Mating

0.100 (2.54mm)

Contact Length - Post

0.125 3.18mm

Shrouding

Unshrouded

Number Of PCB Rows

2

Contact Finish - Post

Nickel

Contact Length - Mating

0.125 3.18mm

PCB Contact Pattern

RECTANGULAR

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Overall Contact Length

0.835 21.21mm

Mating Contact Pitch

0.1 inch

RoHS Status

RoHS Compliant

Products Detail

BBD-112-G-C Overview

A Header package is included with it.Its mounting type is Through Hole.Packaging is performed using a Tube case.It is part of the BBD Series of products.Through Hole mounts the part.There is no operating temperature for the device.

BBD-112-G-C Features

BBD series

BBD-112-G-C Applications

There are a lot of Samtec Inc.
BBD-112-G-C Rectangular Connectors applications.

Embedded systems
Datacom
Communication
Medical technology
Military Technology
Measuring & Control Technology
Instrumentation
Automotive Electronics
Telecommunications
Data Technology

Documents

Datasheets:

BBD-112-G-C-Samtec-datasheet-96836919.pdf BBD-112-G-C-Samtec-datasheet-118884233.pdf

Product FAQ

1. Is BBD-112-G-C available for RFQ?

Yes. BBD-112-G-C by Samtec is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for BBD-112-G-C?

Pricing for BBD-112-G-C can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of BBD-112-G-C?

BBD-112-G-C is a Samtec Headers & Wire Housings with Packaging: Tube and Moisture Sensitivity Level (MSL): 1 (Unlimited) and Number of Positions Loaded: All. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for BBD-112-G-C?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can BBD-112-G-C be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to BBD-112-G-C?

Yes. If BBD-112-G-C is unavailable, obsolete, or does not meet your required lead time, we can help check similar Samtec Headers & Wire Housings parts or compatible alternatives.
