SLA5022

Name: SLA5022
Brand: SANKEN
SKU: SLA5022
Availability: InStock

Product FAQ

1. Is SLA5022 available for RFQ?

Yes. SLA5022 by SANKEN is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for SLA5022?

Pricing for SLA5022 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of SLA5022?

SLA5022 is a SANKEN Transistors with RDS(ON) 10V Max: 0.22Ω and RDS(ON) 10V Typ: 0.17Ω. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for SLA5022?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can SLA5022 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to SLA5022?

Yes. If SLA5022 is unavailable, obsolete, or does not meet your required lead time, we can help check similar SANKEN Transistors parts or compatible alternatives.

Part No:

Transistors

Manufacturer:

SANKEN

Description:

SLA5022 is a combination of PNP Darlington transistor and N-channel MOSFET designed for 3-phase motor drive applications.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Package

SLA (12-pin)

Ciss Typ

400pF

Cob Typ Pnp

150pF

Coss Typ

160pF

FT Typ Pnp

120MHz

HFE Max

12000

HFE Min

2000

HFE Typ

5000

-0.5A

ICBO Max

-10µA

IDSS Max

250µA

IEBO Max

-5mA

Products Detail

The SLA5022 is a monolithic integrated circuit combining a PNP Darlington transistor and an N-channel MOSFET in a single 12-pin package. It features high current capability, low on-resistance, and fast switching characteristics. The device includes built-in protection diodes and resistors, making it suitable for driving 3-phase motors with efficient thermal management and reliable performance.

Key Features

PNP Darlington + N-channel MOSFET combination, High current capability: ±6A continuous, ±10A pulse, Low RDS(ON): 0.17Ω typ at VGS=10V, Fast switching: ton 80ns, toff 50ns, High hFE: 2000-12000, Built-in protection diodes and resistors, Thermal protection, 12-pin package
