TS32101-QFNR [Semtech]

TS32101-QFNR Overview

For optimal performance, this voltage regulator uses the Tape & Reel (TR) package. In this voltage regulator, there are 16 terminations. As a matter of fact, the type of analog IC that this voltage regulator 12v is equipped with is called SWITCHING REGULATOR. Space savings are achieved by placing this voltage regulator in the 16-VFQFN Exposed Pad package. There are 1 outputs on DC DC switching regulator. Adjusting voltage regulator's output pins generate Adjustable output. There is a switching regulator that is compatible with the Surface Mount mounting. As long as its operating temperature is -40°C~85°C TA, dc to dc voltage regulator should perform well. There is a switching frequency of 2MHz for this voltage regulator 12v. Input voltage 1.8V is the dc to dc voltage regulator's minimum input voltage required for operation of the voltage regulators. The output voltage (Min/Fixed) of this voltage regulator 12v is 1.2V. This voltage regulator 12v offers maximum design flexibility with an output current of 2A. Listed under the subcategory of Switching Regulator or Controllers is this voltage regulator 12v. In order for this switching regulator to work properly, the output voltage should be at least 1.2VV. There is a maximum output voltage of 5.5V from this voltage regulator 12v.

TS32101-QFNR Features

1 outputs

TS32101-QFNR Applications

There are a lot of Semtech Corporation
TS32101-QFNR Voltage Regulators applications.

• Automation technology
• CMM
• Various precision measuring instruments
• Various precision measuring detectors
• Flaw detection equipment
• Balance equipment
• Industrial robots
• Industrial controllers
• Die casting equipment
• Injection molding machinery
