CC-ANTENNA-DK [Texas Instruments]

Name: CC-ANTENNA-DK
Brand: Texas Instruments
SKU: CC-ANTENNA-DK
Availability: InStock

Part No:

CC-ANTENNA-DK

Category:

Development Tools

Manufacturer:

Texas Instruments

Description:

Design Note DN031 provides an overview of the CC-Antenna-DK development kit, which includes 16 antenna boards and calibration boards for frequencies from 136 MHz to 2480 MHz.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Board Height

95 mm

Board Width Max

45 mm

Board Width Min

20 mm

Dielectric Constant

4.2

Frequency Range

136MHz ~ 2480MHz

Number Of Boards

16

Pcb Panel Size

A4

Pcb Thickness

1.6 mm

Products Detail

The CC-Antenna-DK is an A4-sized PCB panel containing 16 boards (13 antenna designs and 3 calibration boards). Each board can be snapped out. The antennas are designed for connecting to an EM board on the EB platform and include matching networks for different ground plane sizes. The kit covers frequencies from 136 MHz to 2480 MHz and includes PCB, chip, and wire antennas.

Key Features

Frequency range: 136 MHz to 2480 MHz
16 boards (13 antennas and 3 calibration boards)
Matching networks for different ground plane sizes
Antennas categorized by frequency and type (PCB, Chip, Wire)
Includes calibration boards (OPEN, SHORT, LOAD)
Designed for EM board on EB platform.

Documents

Datasheets:

CC-ANTENNA-DK-Texas-Instruments-datasheet-17289811.pdf

Product FAQ

1. Is CC-ANTENNA-DK available for RFQ?

Yes. CC-ANTENNA-DK by Texas Instruments is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for CC-ANTENNA-DK?

Pricing for CC-ANTENNA-DK can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of CC-ANTENNA-DK?

CC-ANTENNA-DK is a Texas Instruments Development Tools with Dielectric Constant: 4.2 and Number Of Boards: 16. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for CC-ANTENNA-DK?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can CC-ANTENNA-DK be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to CC-ANTENNA-DK?

Yes. If CC-ANTENNA-DK is unavailable, obsolete, or does not meet your required lead time, we can help check similar Texas Instruments Development Tools parts or compatible alternatives.
