CC1125RHMT [Texas Instruments]

The CC1125 is an ultra-high performance RF narrowband transceiver. It integrates all filters, eliminating the need for external SAW/IF filters. Designed for ISM/SRD bands (164-192 MHz, 274-320 MHz, 410-480 MHz, 820-960 MHz), it supports packet handling, data buffering, burst transmissions, clear channel assessment, link quality indication, and Wake-On-Radio. Key features include excellent receiver sensitivity (-129 dBm at 300 bps), programmable output power up to +16 dBm, configurable data rates (0-200 kbps), multiple modulation formats (2-FSK, 2-GFSK, 4-FSK, 4-GFSK, MSK, OOK), and seamless integration with CC1190 for extended range. Controlled via SPI interface, it operates from 2.0V to 3.6V with ultra-low power consumption.
