Name: LM3S1J11-IBZ50-C1
Brand: Texas Instruments
SKU: LM3S1J11-IBZ50-C1

Type

Parameter

Mounting Type

Surface Mount

Package / Case

108-LFBGA

Surface Mount

YES

Number of Pins

108

Operating Temperature

-40°C~85°C TA

Packaging

Tray

Series

Stellaris® ARM® Cortex®-M3S 1000

Part Status

Obsolete

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

108

Technology

CMOS

Terminal Position

BOTTOM

Terminal Form

BALL

Supply Voltage

1.2V

Terminal Pitch

0.8mm

Frequency

50MHz

Base Part Number

LM3S1J11

Pin Count

108

Supply Voltage-Min (Vsup)

1.08V

Interface

I2C, IrDA, LIN, SPI, UART, USART

Memory Size

128kB

Oscillator Type

Internal

Number of I/O

RAM Size

20K x 8

Voltage - Supply (Vcc/Vdd)

1.08V~3.6V

uPs/uCs/Peripheral ICs Type

MICROCONTROLLER

Core Processor

ARM® Cortex®-M3

Peripherals

Brown-out Detect/Reset, DMA, POR, PWM, WDT

Program Memory Type

FLASH

Core Size

32-Bit

Program Memory Size

128KB 128K x 8

Connectivity

I2C, IrDA, LINbus, Microwire, SPI, SSI, UART/USART

Bit Size

Data Converter

A/D 8x10b

Watchdog Timer

Yes

Has ADC

YES

DMA Channels

YES

Data Bus Width

32b

PWM Channels

YES

DAC Channels

Number of Timers/Counters

Core Architecture

ARM

Length

10mm

Height Seated (Max)

1.5mm

Radiation Hardening

RoHS Status

RoHS Compliant

LM3S1J11-IBZ50-C1 Overview
