PT6204A [Rochester]

Name: PT6204A
Brand: Rochester
SKU: PT6204A
Availability: InStock

Part No:

PT6204A

Category:

DC/DC Converters

Manufacturer:

Rochester

Description:

2 AMP HIGH-PERFORMANCE ADJUSTABLE ISR WITH ON/OFF CONTROL

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Current Limit

4.5A

Line Regulation

±0.5%

Load Regulation

±0.5%

Mechanical Shock

500 G's

Mechanical Vibration

15 G's

Output Current

2.0 Amps

Overshoot

5.0%

Overshoot Typ

3.0%

PT6202 Efficiency

90%

PT6202 Input Voltage Max

30 VDC

PT6202 Input Voltage Min

7.25 VDC

PT6202 Operating Temperature Max

+60°C

PT6202 Operating Temperature Min

-40°C

PT6202 Switching Frequency Max

800KHz

PT6202 Switching Frequency Min

500KHz

PT6203 Efficiency

85%

PT6203 Input Voltage Max

26 VDC

PT6203 Input Voltage Min

7 VDC

PT6203 Operating Temperature Max

+85°C

PT6203 Operating Temperature Min

-40°C

PT6203 Switching Frequency Max

600KHz

PT6203 Switching Frequency Min

400KHz

PT6204 Efficiency

93%

PT6204 Input Voltage Max

30 VDC

PT6204 Input Voltage Min

14.5 VDC

PT6204 Operating Temperature Min

-40°C

PT6204 Switching Frequency Max

800KHz

PT6204 Switching Frequency Min

500KHz

Package

SIP (0.36" x 1.64" x 0.60"(H))

Quiescent Current

10mA

Relative Humidity

0% ~ 95%

Ripple Noise

±2%

Short Circuit Current

5.0A

Shutdown Current

100µA

Storage Temperature

-40°C ~ +125°C

Thermal Resistance Pt6202

30°C/W

Thermal Resistance Pt6203

25°C/W

Thermal Resistance Pt6204

35°C/W

Transient Response Max

200 µs

Transient Response Typ

100 µs

Weight

8.5 grams

Products Detail

The PT6200 Series is a line of 2 Amp, high-performance adjustable output voltage integrated switching regulators (ISRs) designed for battery powered or other equipment requiring high efficiency and small size. It features on/off control (ground off), internal short circuit protection, over-temperature protection, and a small SIP footprint. Typical efficiency is 90%. Quiescent current in shutdown mode is less than 100µA.

Key Features

Efficiency: 90% typical, Adjustable Output Voltage, Internal Short Circuit Protection, Over-Temperature Protection, On/Off Control (Ground Off), Small SIP Footprint: 0.36" x 1.64" x 0.60"(H), Low Quiescent Current: <100µA in shutdown

Application scenarios

Battery powered equipment
on-board power conversion

Documents

Datasheets:

PT6200 Series PT6204A-Texas-Instruments-datasheet-10254408.pdf PT6204A-Texas-Instruments-datasheet-34368.pdf

Product FAQ

1. Is PT6204A available for RFQ?

Yes. PT6204A by Rochester is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for PT6204A?

Pricing for PT6204A can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of PT6204A?

PT6204A is a Rochester DC/DC Converters with PT6202 Operating Temperature Max: +60°C and PT6202 Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for PT6204A?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can PT6204A be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to PT6204A?

Yes. If PT6204A is unavailable, obsolete, or does not meet your required lead time, we can help check similar Rochester DC/DC Converters parts or compatible alternatives.
