PT6346A [Rochester]

Name: PT6346A
Brand: Rochester
SKU: PT6346A
Availability: InStock

Part No:

PT6346A

DC/DC Converters

Manufacturer:

Rochester

Description:

The PT6340 Excalibur™ power modules are a series of high performance Integrated Switching Regulators (ISRs), housed in a thermally efficient solderable copper case.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

External Input Capacitance Min

100µF

External Output Capacitance Max

1000µF

External Output Capacitance Min

330µF

Flammability

UL 94V-0

Input Voltage

10.8V ~ 13.2V

Mean Time Between Failures (MTBF)

8.8e6 hours

Mechanical Shock

500 G's

Mechanical Vibration

20 G's

Operating Temperature

-40°C ~ +85°C

Output Current

Output Ripple

Products Detail

The PT6340 series operates from a 12V input voltage bus to produce a high-output low-voltage power source, ideal for powering the industry’s latest DSP and microprocessors. The series includes standard output bus voltages ranging from 5VDC to 1.2VDC. The innovative copper case construction provides superior thermal performance in a small footprint. Both through-hole and surface mount pin configurations are available. The operating features include external output voltage adjustment, an On/Off inhibit, and short-circuit protection. A 100µF input and 330µF output capacitor are required for proper operation.

Key Features

6A Output Current
Input Voltage Range: 10.8 V to 13.2 V
90% Efficiency
Adjustable Output Voltage
Standby Function
Short Circuit Protection
Small Footprint (0.61 in2)
Solderable Copper Case
8.8 106 Hours MTBF

Application scenarios

DSP and microprocessors

Documents

Datasheets:

PT6340 Series

Product FAQ

1. Is PT6346A available for RFQ?

Yes. PT6346A by Rochester is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for PT6346A?

Pricing for PT6346A can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of PT6346A?

PT6346A is a Rochester DC/DC Converters with Transient Response Voltage Deviation: ±60mV and Mean Time Between Failures (MTBF): 8.8e6 hours. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for PT6346A?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can PT6346A be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to PT6346A?

Yes. If PT6346A is unavailable, obsolete, or does not meet your required lead time, we can help check similar Rochester DC/DC Converters parts or compatible alternatives.
