OP223TX [TT Electronics]

Name: OP223TX
Brand: TT Electronics
SKU: OP223TX
Availability: InStock

Part No:

OP223TX

Category:

LEDs

Manufacturer:

TT Electronics

Description:

Hermetic Infrared Emitting Diodes including OP123, OP124 (GaAs, 935 nm) and OP223, OP224 (GaAlAs, 890 nm) in miniature hermetically sealed pill packages.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Reverse Voltage

2.0V

Power Dissipation

150mW

Reverse Current

100µA

Peak Forward Current

1.0A

Lead Soldering Temperature

260°C

Continuous Forward Current

100mA

Operating Temperature

-65°C ~ +125°C

Storage Temperature

-65°C ~ +150°C

Emission Angle

24°

OP123 Apertured Radiant Incidence Min

0.40mW/cm2

OP123 Fall Time

500 ns

OP123 Forward Voltage Max

1.50V

OP123 Rise Time

1000 ns

OP123 Spectral Bandwidth

50 nm

OP123 Spectral Shift

+0.30 nm/°C

OP123 Wavelength

935 nm

OP124 Apertured Radiant Incidence Min

1.00mW/cm2

OP124 Fall Time

500 ns

OP124 Forward Voltage Max

1.80V

OP124 Rise Time

1000 ns

OP124 Spectral Bandwidth

50 nm

OP124 Spectral Shift

+0.30 nm/°C

OP124 Wavelength

935 nm

OP223 Apertured Radiant Incidence Min

1.00mW/cm2

OP223 Fall Time

250 ns

OP223 Rise Time

500 ns

OP223 Spectral Bandwidth

80 nm

OP223 Spectral Shift

+0.18 nm/°C

OP223 Wavelength

890 nm

OP224 Apertured Radiant Incidence Min

3.50mW/cm2

OP224 Fall Time

250 ns

OP224 Rise Time

500 ns

OP224 Spectral Bandwidth

80 nm

OP224 Spectral Shift

+0.18 nm/°C

OP224 Wavelength

890 nm

Products Detail

The OP123 and OP124 are 935 nm gallium arsenide infrared emitting diodes with high power output and enhanced temperature range. The OP223 and OP224 are 890 nm gallium aluminum arsenide diodes featuring narrow irradiance patterns, high on-axis intensity, and higher power output than GaAs at equivalent drive currents. All devices are hermetically sealed, designed for direct PC board mounting, and spectrally matched to OP300/OP600/OP640 series. They offer excellent coupling efficiency with silicon's peak response and enable high-density mounting.

Key Features

Hermetically sealed package
Mechanically and spectrally matched to other OPTEK devices
Designed for direct mount to PCBoard
Enhanced temperature range
High power output
Narrow irradiance pattern (OP223/224)
High on-axis intensity
Higher power output than GaAs at equivalent drive currents (OP223/224)
Wavelength matched to silicon's peak response
Small package size for high device density mounting

Application scenarios

Non-contact reflective object sensor
Assembly line automation
Machine automation
Machine safety
End of travel sensor
Door sensor

Documents

Datasheets:

OP123,124,223,224 OP223TX-Optek-datasheet-164915.pdf OP223TX-Optek-datasheet-21070107.pdf

PCN Obsolescence/ EOL:

Mult Dev EOL 2/Sep/2019

Product FAQ

1. Is OP223TX available for RFQ?

Yes. OP223TX by TT Electronics is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for OP223TX?

Pricing for OP223TX can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of OP223TX?

OP223TX is a TT Electronics LEDs with OP123 Apertured Radiant Incidence Min: 0.40mW/cm2 and OP124 Apertured Radiant Incidence Min: 1.00mW/cm2. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for OP223TX?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can OP223TX be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to OP223TX?

Yes. If OP223TX is unavailable, obsolete, or does not meet your required lead time, we can help check similar TT Electronics LEDs parts or compatible alternatives.
