2N4036 PBFREE [Unknown]

2N4036 PBFREE Overview

This device has a DC current gain of 40 @ 150mA 10V, which is the ratio between the base current and the collector current.A VCE saturation (Max) of 650mV @ 15mA, 150mA means Ic has reached its maximum value(saturated).As you can see, the part has a transition frequency of 60MHz.Collector Emitter Breakdown occurs at 65VV - Maximum voltage.

2N4036 PBFREE Features

the DC current gain for this device is 40 @ 150mA 10V
the vce saturation(Max) is 650mV @ 15mA, 150mA
a transition frequency of 60MHz

2N4036 PBFREE Applications

There are a lot of Central Semiconductor Corp
2N4036 PBFREE applications of single BJT transistors.

• Inverter
• Interface
• Driver
• Muting
