    BPJF01X [Unknown]

    BPJF01X
    BPJF01X

    Part No:

    BPJF01X

    Category:

    Audio & Video Connectors

    Manufacturer:

    Unknown

    RoHS Status:

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Factory Lead Time
    12 Weeks
    Contact Plating
    Nickel, Silver
    Mount
    Panel
    Mounting Type
    Panel Mount
    Body Material
    Brass
    Contact Material - Plating
    Nickel
    Packaging
    Bulk
    Published
    2007
    Feature
    Grounding Tab, Mounting Hardware
    Part Status
    Active
    Moisture Sensitivity Level (MSL)
    Not Applicable
    Number of Terminations
    2
    Termination
    Solder Eyelet(s)
    Connector Type
    Phono (RCA) Jack
    Gender
    Female
    MIL Conformance
    NO
    DIN Conformance
    NO
    IEC Conformance
    NO
    Option
    GENERAL PURPOSE
    Orientation
    Straight
    Shielding
    Unshielded
    Depth
    10.2mm
    Insulation Color
    Black
    Number of Ports
    1
    Number of Poles
    2
    Thread Size
    1/4-32
    Number of Positions/Contacts
    2 Conductors, 2 Contacts
    Includes
    3 pcs - 1 Connector, 1 Nut, 1 Washer
    Internal Switch(s)
    Does Not Contain Switch
    Body Color
    Silver
    Panel Hole Size
    0.402 10.20mm
    Industry Recognized Mating Diameter
    3.20mm ID, 9.00mm OD (RCA)
    Actual Diameter
    0.134 (3.40mm ID), 0.325 (8.25mm OD)
    Signal Lines
    Mono
    Length
    21.6mm
    RoHS Status
    RoHS Compliant

    Documents

    Datasheets:

    BPJF01X-Switchcraft-datasheet-26675.pdf
    Product FAQ

    1. Is BPJF01X available for RFQ?

    Yes. BPJF01X by Unknown is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for BPJF01X?

    Pricing for BPJF01X can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of BPJF01X?

    BPJF01X is a Unknown Audio & Video Connectors with Packaging: Bulk and Industry Recognized Mating Diameter: 3.20mm ID, 9.00mm OD (RCA) and Moisture Sensitivity Level (MSL): Not Applicable. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for BPJF01X?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can BPJF01X be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to BPJF01X?

    Yes. If BPJF01X is unavailable, obsolete, or does not meet your required lead time, we can help check similar Unknown Audio & Video Connectors parts or compatible alternatives.
