| Type | Parameter |
|---|---|
| Factory Lead Time | 8 Weeks |
| Contact Material | Brass |
| Mount | Panel, Through Hole |
| Mounting Type | Panel Mount, Through Hole |
| Housing Material | Thermoplastic |
| Contact Material - Plating | Tin |
| Packaging | Bulk |
| Series | Hi-D JAX® MN-11* |
| Published | 2005 |
| JESD-609 Code | e3 |
| Feature | Mounting Hardware, Thread Lock |
| Part Status | Active |
| Moisture Sensitivity Level (MSL) | Not Applicable |
| Number of Terminations | 5 |
| Termination | Solder |
| Connector Type | Phone Jack |
| Max Operating Temperature | 65°C |
| Min Operating Temperature | -20°C |
| Gender | Female |
| Voltage - Rated | 48V |
| Contact Finish - Mating | GOLD |
| MIL Conformance | NO |
| DIN Conformance | NO |
| IEC Conformance | NO |
| Option | GENERAL PURPOSE |
| Orientation | Straight |
| Shielding | Unshielded |
| Depth | 15.9mm |
| Number of Contacts | 3 |
| Housing Color | Black |
| Max Current Rating | 3A |
| Number of Ports | 1 |
| Number of Poles | 3 |
| Max Voltage Rating (DC) | 48V |
| Thread Size | 3/8-32 |
| Number of Positions/Contacts | 3 Conductors, 5 Contacts |
| Includes | 3 pcs - 1 Connector, 1 Nut, 1 Washer |
| Internal Switch(s) | Two Switches |
| Panel Hole Size | 0.375 9.52mm |
| Industry Recognized Mating Diameter | 6.35mm (0.250, 1/4) - Headphone |
| Actual Diameter | 0.250 (6.35mm) |
| Signal Lines | Stereo (3 Conductor, TRS) |
| Length | 15.9mm |
| RoHS Status | RoHS Compliant |
Yes. MN114BPCX by Unknown is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.
Pricing for MN114BPCX can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.
MN114BPCX is a Unknown Audio & Video Connectors with Packaging: Bulk and Industry Recognized Mating Diameter: 6.35mm (0.250, 1/4) - Headphone and Moisture Sensitivity Level (MSL): Not Applicable. Review the product details or submit an RFQ if you need confirmation before purchase.
Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.
If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.
Yes. If MN114BPCX is unavailable, obsolete, or does not meet your required lead time, we can help check similar Unknown Audio & Video Connectors parts or compatible alternatives.
