    E20-00M [ZF Electronics]

    E20-00M
    E20-00M

    Part No:

    E20-00M

    Category:

    Switches

    Manufacturer:

    ZF Electronics

    RoHS Status:

    Product FAQ

    1. Is E20-00M available for RFQ?

    Yes. E20-00M by ZF Electronics is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for E20-00M?

    Pricing for E20-00M can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of E20-00M?

    E20-00M is a ZF Electronics Switches with Packaging: Bulk and Moisture Sensitivity Level (MSL): 1 (Unlimited) and Max Operating Temperature: 105°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for E20-00M?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can E20-00M be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to E20-00M?

    Yes. If E20-00M is unavailable, obsolete, or does not meet your required lead time, we can help check similar ZF Electronics Switches parts or compatible alternatives.

    RFQ

    Part Number:

    E20-00M

    Manufacturer:

    ZF Electronics

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Factory Lead Time
    18 Weeks
    Contact Material
    Brass, Cadmium, Silver
    Contact Plating
    Silver
    Mount
    Panel, Screw
    Mounting Type
    Panel Mount
    Actuator Material
    Nylon, Thermoplastic
    Operating Temperature
    -40°C~105°C
    Packaging
    Bulk
    Series
    E
    Published
    2008
    Part Status
    Active
    Moisture Sensitivity Level (MSL)
    1 (Unlimited)
    Termination
    Quick Connect
    Max Operating Temperature
    105°C
    Min Operating Temperature
    -40°C
    Current Rating (Amps)
    20A AC
    Orientation
    Straight
    Depth
    16.28mm
    Current Rating
    20A
    Termination Style
    Quick Connect - 0.250 (6.3mm)
    Voltage - Rated AC
    125V
    Actuator Type
    Overtravel Plunger
    Circuit
    DPDT
    Switch Function
    On-Mom
    Max Voltage Rating (AC)
    250V
    Max Current Rating
    20A
    Electrical Life
    6,000 Cycles
    Throw Configuration
    DPDT
    Operating Force
    1280gf
    Overtravel
    0.187 (4.75mm)
    Differential Travel
    0.015 (0.38mm)
    Pretravel
    0.100 (2.5mm)
    Operating Position
    0.776 (19.7mm)
    Height
    16.3mm
    Length
    66.67mm
    Width
    46.3mm
    RoHS Status
    RoHS Compliant
    Lead Free
    Lead Free

    Documents

    Datasheets:

    E19,20, G20 Series Datasheet
