Name: FR85BR02
Brand: GeneSiC Semiconductor
SKU: FR85BR02

FR85BR02 [GeneSiC Semiconductor]

Part No:

FR85BR02

Diodes & Rectifiers

Manufacturer:

GeneSiC Semiconductor

Description:

Standard, Reverse Polarity Diode Rectifier Fast Recovery =< 500ns, > 200mA (Io) 1.4V @ 85A -40°C~125°C 25?A @ 100V 1-Termination Bulk DO-203AB, DO-5, Stud Chassis, Stud Mount

Package:

-

RoHS Status:

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Lifecycle Status

PRODUCTION (Last Updated: 6 months ago)

Factory Lead Time

10 Weeks

Mount

Chassis, Stud

Mounting Type

Chassis, Stud Mount

Package / Case

DO-203AB, DO-5, Stud

Diode Element Material

SILICON

Packaging

Bulk

Pbfree Code

yes

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

ECCN Code

EAR99

HTS Code

8541.10.00.80

Terminal Position

UPPER

Terminal Form

SOLDER LUG

JESD-30 Code

O-MUPM-D1

Operating Temperature (Max)

125°C

Number of Elements

Configuration

SINGLE

Speed

Fast Recovery =< 500ns, > 200mA (Io)

Diode Type

Standard, Reverse Polarity

Voltage - Forward (Vf) (Max) @ If

1.4V @ 85A

Case Connection

ANODE

Forward Current

85A

Operating Temperature - Junction

-40°C~125°C

Max Surge Current

1.369kA

Max Reverse Voltage (DC)

100V

Average Rectified Current

85A

Number of Phases

Reverse Recovery Time

200 ns

Max Repetitive Reverse Voltage (Vrrm)

100V

Reverse Voltage

100V

Recovery Time

200 ns

RoHS Status

RoHS Compliant

Products Detail

FR85BR02 Overview

There is no reason to reverse the voltage at 100V.Devices like this have an average rectified current of 85A volts.There is no limit to the forward current value.Surge current can reach maximum value 1.369kA.On the data sheets, the peak reverse is indicated by the data chart as 25?A.

FR85BR02 Features

an average rectified current of 85A volts
the peak reverse is 25?A

FR85BR02 Applications

There are a lot of GeneSiC Semiconductor
FR85BR02 applications of single-phase diode rectifier.

DC motor control and drives
Battery chargers
Welders
Power converters
Reverse Polarity Protection
Ultra High-Speed Switching
Freewheeling
Polarity Protection Diode
Recirculating Diode
Switching Diode

Key Features

No key features available

Application scenarios

No application scenarios available
