    ATM90E36A-RD [Microchip]

    ATM90E36A-RD
    ATM90E36A-RD

    Part No:

    ATM90E36A-RD

    Category:

    Other Modules

    Manufacturer:

    Microchip

    Description:

    Enhanced Poly-Phase High-Performance Wide-Span Energy Metering IC

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Supply Voltage
    3.3V
    Operating Temperature
    -40°C ~ +85°C
    Package
    TQFP48
    Operating Voltage
    2.8V ~ 3.6V
    Oscillator Frequency
    16.384MHz
    Temperature Sensor Accuracy
    ±1°C (typical)

    Products Detail

    The M90E36A is a poly-phase high performance wide-dynamic range metering IC incorporating 7 independent 2nd order sigma-delta ADCs for three voltage channels and four current channels. It features an embedded DSP for energy calculation (active, reactive, apparent, fundamental, harmonic) and measurement parameters (Vrms, Irms, power, frequency, power factor, phase angle). Includes THD and DFT analysis for harmonics, event detection capabilities, multiple power modes, and a four-wire SPI interface with DMA support. Designed for poly-phase multi-function meters and data acquisition terminals with long-term stability.

    Key Features

    • Compliance with IEC62052-11, IEC62053-22/23, ANSI C12.1/12.20
    • ±0.1% active energy / ±0.2% reactive energy accuracy (6000:1 dynamic range)
    • 6 ppm/℃ temperature coefficient (reference voltage)
    • Single-point calibration per phase
    • ±1°C temperature sensor accuracy
    • Electrical parameter measurement (±0.5% fiducial error)
    • Independent energy registers (active/reactive/apparent)
    • Programmable startup/no-load thresholds
    • Dedicated ADC/gains for phase/neutral current
    • Programmable power modes (Normal, Idle, Detection, Partial)
    • Fundamental/harmonic energy registers (CF3/CF4)
    • THD/DFT for 2-32 order harmonics
    • Event detection (sag, phase loss, reverse sequence, overcurrent, THD+N)
    • 3.3V single supply (2.8V-3.6V range)
    • Four-wire SPI with DMA
    • Programmable sag detection/zero-crossing
    • CF1-CF4 pulse outputs
    • 16.384 MHz crystal oscillator (on-chip caps)
    • TQFP48 package
    • -40°C to +85°C operation

    Application scenarios

    • Poly-phase energy meters (class 0.2S, 0.5S, 1)
    • Data Acquisition Terminal
    • Power monitoring instruments

    Documents

    Datasheets:

    ATM90E36A DataSheet
