EMC1001-AFZQ-TR Overview

As a safety precaution, these analog sensors are packaged in the Tape & Reel (TR). For the protection of the analog sensors, they are packaged in SOT-23-6 packages. The sensor has a pin count of 6 for proper operation. It is possible that the analog sensors are operating with a current of 10?A. DC circuits containing this sensor should be able to supply a maximum voltage of 3.6V. However, the minimum voltage that this magnetic switch can supply in the DC circuit is 3V. Analog sensors are capable of providing a voltage of 3.3V when they are in operation. As a result, this sensor is capable of supplying 50?A current to operate. In order to achieve the best performance, the sensor's current output should be 47?A.

EMC1001-AFZQ-TR Features

Moisture Sensitivity Level (MSL): 3 (168 Hours)
Tape & Reel (TR) Package
Operating Temperature: -25°C~125°C
Supply Voltage: 3V~3.6V
6 Pins
Local Sensing Temperature: -25°C~125°C
Highest (Lowest) Accuracy: ±1.5°C (±3°C)
Sensor Type: Digital, Local

EMC1001-AFZQ-TR Applications

There are a lot of Microchip Technology
EMC1001-AFZQ-TR Analog & Digital Sensors applications.

• HVAC
• Disk Drives
• Automotive
• Portable Medical Instruments
• Computers
• Battery Management
• Printers
• Power Supply Modules
• FAX Machines
• Mobile Phones
