Name: ENC28J60-I/SP
Brand: Microchip
SKU: ENC28J60-I/SP

Part number

RFQ List

Part number

ENC28J60-I/SP [Microchip]

Part No:

ENC28J60-I/SP

Communication & Networking ICs

Manufacturer:

Microchip

Description:

Microchip\u0027s ENC28J60 is a 28-pin, 10BASE-T stand alone Ethernet Controller with on board MAC \u0026 PHY, 8 Kbytes of Buffer RAM and an SPI serial interface.

Package:

-

RoHS Status:

-

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

DownstreamPorts

ESD Rating

Port Speed

10Mbps

Fiber Support

Interrupt Pin

LEDS

LinkMDCableDiag

Maximum Speed

25Mhz

NoofEtherPorts

Number of VLANs

TX/RX Ram Buffer

Temperature Range Max

Temperature Range Min

-40

Digital I/O Voltage

3.3

Products Detail

Microchip's ENC28J60 is a 28-pin, 10BASE-T stand alone Ethernet Controller with on board MAC & PHY, 8 Kbytes of Buffer RAM and an SPI serial interface. With a small foot print package size the ENC28J60 minimizes complexity, board space and cost. Target applications include VoIP, Industrial Automation, Building Automation, Home Control, Security and Instrumentation. Ethernet Application Design Center

Microchip's complimentary and confidential MicroCHECK design review service, which offers insight from the initial concept to the final PCB layout, is available to customers who are using our products in their projects. You can confidently submit your design materials in a secure and private setting, and our expert engineers will provide individualized feedback to enhance your design. MicroCHECK design review service is subject to Microchip's Program Terms and Conditions and requires a myMicrochip account.

IEEE 802.3 compatible

Integrated MAC and 10BASE-T

8 Kbyte Transmit/Receive Packet Dual Port Buffer

Programmable Automatic Retransmit on Collision

Internal DMA for fast memory copying

Programmable wake-up on multiple packet formats, including Magic Packet®, Unicast, Multicast, Broadcast, specific packet match or any packet

Hardware assisted IP checksum

Programmable pattern matching of up to 64 bytes within packet at user defined offset

Packaging: SOIC- SPDIP- SSOP- QFN (6x6 mm)

VoIP
Industrial and Building Automation
Home Control and Security

Key Features

No key features available

Application scenarios

No application scenarios available

Documents

No documents available
