    5. EVB-USB3803 Microchip

    EVB-USB3803 [Microchip]

    EVB-USB3803
    EVB-USB3803

    Part No:

    EVB-USB3803

    Category:

    Other Modules

    Manufacturer:

    Microchip

    Description:

    The SMSC USB3803 is a low-power, USB 2.0 hub controller with three downstream ports. It supports low-speed, full-speed, and hi-speed downstream devices.

    RoHS Status:

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    TypeParameter
    Package
    25-Ball WLCSP (1.95x1.95mm, 0.4mm pitch)
    RoHS Status
    RoHS Compliant
    RoHS Status
    RoHS Compliant
    ESD Protection
    ±15kV (air), ±8kV (contact)
    Halogen Free
    Yes
    Packing
    Tape and reel
    Reel Size
    3000 pieces
    Reference Clock
    12, 19.2, 26, 38.4MHz
    Standby Current
    1µA
    USB3803C-1-GL-TR Operating Temperature Max
    70°C
    USB3803C-1-GL-TR Operating Temperature Min
    0°C
    USB3803Ci-1-GL-TR Operating Temperature Max
    85°C
    USB3803Ci-1-GL-TR Operating Temperature Min
    -40°C

    Products Detail

    The USB3803 is optimized for mobile embedded applications, reducing pin-count and power consumption. It features integrated USB switch for bypass mode, battery charger detection, and programmable features such as MultiTRAK, PortMap, PortSwap, PHYBoost, and VariSense. It supports I2C configuration, has internal regulators for single supply operation, and includes advanced power saving modes with 1 μA typical standby current.

    Key Features

    • flexPWR Technology
    • Integrated USB 2.0 Compatible 3-Port Hub
    • Advanced power saving features (1 μA Typical Standby Current)
    • External 12, 19.2, 26, or 38.4MHz clock input
    • Internal 3.3V & 1.2V Voltage Regulators
    • External VBAT and 1.8V dual supply input option
    • USB Battery Charger Detection (DCP, CDP, SDP)
    • Supports Single-TT or Multi-TT configurations
    • Bypass Switch for low power
    • I2C configuration
    • MultiTRAK (dedicated TT per port)
    • PortMap (configurable port mapping)
    • PortSwap (differential pair swapping)
    • PHYBoost (programmable drive strength)
    • VariSense (programmable receiver sensitivity)
    • Internal Short Circuit protection
    • USB Port ESD Protection (±15kV air, ±8kV contact)
    • 25-pin WLCS Package

    Application scenarios

    • Mobile Phones
    • Ultra Mobile PCs
    • Tablet Computers
    • Digital Still Cameras
    • Digital Video Camcorders
    • Gaming Consoles
    • PDAs
    • Portable Media Players
    • GPS Personal Navigation Devices
    • Media Players/Viewers

    Documents

    Datasheets:

    USB3803 BriefUSB3803 Eval Brd Manual

    ConflictMineralStatement:

    Microchip-company-68.pdf
    Product FAQ

    1. Is EVB-USB3803 available for RFQ?

    Yes. EVB-USB3803 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for EVB-USB3803?

    Pricing for EVB-USB3803 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of EVB-USB3803?

    EVB-USB3803 is a Microchip Other Modules with USB3803Ci-1-GL-TR Operating Temperature Max: 85°C and USB3803Ci-1-GL-TR Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for EVB-USB3803?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can EVB-USB3803 be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to EVB-USB3803?

    Yes. If EVB-USB3803 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Other Modules parts or compatible alternatives.
