Name: RNBD451PE-I100
Brand: Microchip
SKU: RNBD451PE-I100

RNBD451PE-I100 [Microchip]

Part No:

RNBD451PE-I100

Wireless Modules

Manufacturer:

Microchip

Description:

The RNBD451, a pre-programmed, Global regulatory certified, RF ready, Bluetooth module, provides a plug-and-play solution that offers the quickest path to revenue for IoT designers.

Package:

-

RoHS Status:

-

Datasheet:

-

Production Status:

In Stock Status:

Specification

Type

Parameter

Wireless Technology

Bluetooth LE

Bluetooth Spec

5.2

TX Output Power (dBm)

RX Sensitivity (dBm)

-102

Operating Temp (°C) Min

-40

Operating Temp (°C) Max

Operating Voltage (V) Min

1.9

Operating Voltage (V) Max

3.6

Deep Sleep Current (μA)

1.5

GPIO

Antenna Type

PCB

Regulatory

FCC, ISED, CE, UKCA, SRRC, MIC, NC, KC

Products Detail

Effortlessly add Bluetooth® Low Energy (LE) 5.2 to your design with our RNBD451PE plug-and-play module. The RNBD451PE is truly plug-and-play – there is no programming, RF-design or regulatory certification required. Part of our Bluetooth LE product portfolio, the RNBD451PE saves time, money and engineering resources which reduces your time to market.

Plug-and-play simplicity: No wireless software development needed, just send commands from any MCU over UART. Supports Host Controller Interface (HCI) mode for Linux/MPU applications.

RF-ready with onboard antenna: RF design is complicated, but with the RNBD451PE module, you don’t have to worry about it. The RNBD451PE module comes with an on-board PCB antenna built for optimal RF performance, saving you time and RF-design hassle.

Global regulatory-certified: RF certification can take a lot of time and money. RNBD451PE modules are pre-certified in US, Canada, Europe, Taiwan, China, Japan, and Korea. Choosing a pre-certified module bypasses the certification process allowing you to focus on your product.

Free mobile app and source code for Android™ and iOS®: Download the app and source code today and get started with creating your own mobile app.

Free personalized design check service: When you choose our products, we will review and provide guidance on the schematic, PCB layout and RF testing of your wireless. Learn more.

New to Bluetooth development? We have a step-by-step guide that walks you through the Bluetooth development process. Learn more.

Related Products

RF-ready MCU module with PCB antenna: WBZ451PE
RF-ready MCU module with U.FL antenna for applications where PCB antenna doesn't work: WBZ451UE
SoC for greater control: PIC32CX1012BZ25048

Lower pin count variant

RF-ready MCU module with PCB antenna: WBZ450PE
RF-ready MCU module with U.FL connector: WBZ450UE
SoC for greater control: PIC32CX1012BZ24032

Smaller memory, Secure Boot variants

RF-ready MCU module with PCB antenna: WBZ351PE
RF-ready MCU module with U.FL antenna: WBZ351UE
SoC for greater control: PIC32CX5109BZ31048

Definable Beacon Feature to Make Various Beacons, such as iBeacon™ and Eddystone™

Bluetooth LE 5.2 stack

ASCII Command Interface API over UART

Host Controller Interface (HCI) Mode

ASCII Commands are Backward Compatible with RN487x Family of Modules

Built-in Microchip Transparent Profile for UART Data Streaming

Over-the-Air (OTA) Remote Configuration

Embedded Enhanced Security

2M Uncoded PHY and Long Range (Coded PHY)

Extended Advertising

Data Length Extensions and Secure Connections

Bluetooth LE Privacy 1.2 with up to Eight Resolvable and Accept Lists

UART based Device Firmware Update (DFU)

Built-in Microchip OTA Profile with Client and Server Role for OTA DFU Execution

Integrated 16 MHz POSC

8 GPIOs that can be Controlled by RN Command

12-bit Analog-to-Digital Converters (ADC) Successive Approximation Register (SAR) Module for Analog to Digital Conversion

Add-on up to 6 16-bit UUID GATT Services (Public Service), 4 128-bit UUID GATT Services (Private Service), and Each Service Includes up to 8 Characteristic Attributes

Supports Bluetooth LE Advertiser, Observer, Central and Peripheral Roles

Supports Bluetooth LE GATT Client and Server Roles

Supports up to 6 Concurrent Bluetooth LE Connections

Operating Voltage: 1.9 to 3.6V (3.3V typical)
Temperature Range: -40 to +85°C

Industrial, Scientific and Medical (ISM) Band: 2.402 to 2.480 GHz Operation
Channels: 0 to 39
Up to +12 dBm Programmable Transmit Output Power
Digital Received Signal Strength Indicator (RSSI)

-95 dBm for Bluetooth LE 1 Mbps
-92 dBm for Bluetooth LE 2 Mbps
-102 dBm for Bluetooth LE 125 Kbps
-99 dBm for Bluetooth LE 500 Kbps

FCC (USA)
CE (EU)
UKCA (UK)
ISED (Canada)
SRRC (China)
MIC (Japan)
NC (Taiwan)
KC (South Korea)
