ABS1512503 [Panasonic]

Name: ABS1512503
Brand: Panasonic
SKU: ABS1512503
Availability: InStock

Part No:

ABS1512503

Category:

Switches

Manufacturer:

Panasonic

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

11 Weeks

Mounting Type

Through Hole

Surface Mount

NO

Operating Temperature

-40°C~85°C

Packaging

Bulk

Series

ABS

Published

2008

Part Status

Active

Moisture Sensitivity Level (MSL)

Not Applicable

ECCN Code

EAR99

HTS Code

8536.50.70.00

Voltage - Rated DC

30V

Current Rating (Amps)

2A AC/DC

Ingress Protection

IP50 - Dust Protected

Termination Style

PC Pin

Voltage - Rated AC

125V

Body Length or Diameter

19.8mm

Body Breadth

6.4 mm

Actuator Type

Lever, Straight

Circuit

SPDT

Switch Function

On-Mom

Contact Current(DC)-Max

2A

Sealing

ENVIRONMENTALLY SEALED; IP67

Contact Voltage(DC)-Max

30V

Electrical Life

50,000 Cycles

Mechanical Life

5,000,000 Cycles

Switch Type

SNAP ACTING/LIMIT SWITCH

Operating Force

55gf

Contact Current(AC)-Max

2A

Contact (AC) Max Rating R Load

2A@250VAC

Overtravel

0.047 (1.2mm)

Contact Voltage(AC)-Max

250V

Differential Travel

0.031 (0.8mm)

Pretravel

0.110 (2.8mm)

Operating Position

0.345 (8.8mm)

Release Force

3.500gf

Actuator Travel

4 mm

Pre-Travel-Max

2.8 mm

Body Height

11.1mm

RoHS Status

RoHS Compliant

Documents

Datasheets:

ABS(BS) Switches Datasheet

1. Is ABS1512503 available for RFQ?

Yes. ABS1512503 by Panasonic is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for ABS1512503?

Pricing for ABS1512503 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of ABS1512503?

ABS1512503 is a Panasonic Switches with Packaging: Bulk and Moisture Sensitivity Level (MSL): Not Applicable and Contact (AC) Max Rating R Load: 2A@250VAC. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for ABS1512503?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can ABS1512503 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to ABS1512503?

Yes. If ABS1512503 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Panasonic Switches parts or compatible alternatives.
