2308A-3DCGI8 [RENESAS]

2308A-3DCGI8 Overview

As a clock IC, it is packaged by the Tape & Reel (TR) method. The 16-SOIC (0.154, 3.90mm Width) package embeds this Clock PLL. There is a Clock PLL called LVTTL which is designed to be the input to this clock generator. Using 1 circuits, the electronic part's full performance can be accessed. RF synthesizers based on this clock provide frequencies up to 133.3MHz maximum. A Surface Mount-shaped electrical component makes it convenient to mount on a panel. There should be 3V~3.6V provided with this RF synthesizer. As determined by the test statistics, the ambient temperature should be set to -40°C~85°C. In this case, we are dealing with a frequency synthesizer that can be used with LVTTL logic levels. As far as this electronic part is concerned, it can be classified as a Multiplier, Zero Delay Buffer component. The related electronic parts of part number IDT2308-3 are listed below.

2308A-3DCGI8 Features

Available in the 16-SOIC (0.154, 3.90mm Width)

2308A-3DCGI8 Applications

There are a lot of Renesas Electronics America Inc.
2308A-3DCGI8 Clock Generators applications.

• Picocells, femtocells and small cells
• Sampling clocks for ADC and DAC
• 1 Gigabit Ethernet
• 10 Gigabit Ethernet
• FPGA and processor clocks
• Line cards used in telephone exchange
• Fiber Channel
• PCI express cards
• Infotainment systems
• Medical equipment
