SLG59H1127VTR [RENESAS]

Part No:

SLG59H1127VTR

Name: SLG59H1127VTR
Brand: RENESAS
SKU: SLG59H1127VTR

Category:Power Supplies

Manufacturer:RENESAS

Description:12V, 15mΩ, 4A Load Switch with Programmable OVP and Power Good Output

Package:-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Lead Count (#)

Temp. Range

-40 to +85°C

Current Monitor Output

Discharge Circuit

Yes

Enable

Active High

FET Pass Device Type

Single N-Channel

IDS (A)

IDS Channel 1 (A)

Internal TVS Surge Protection

Output Discharge Circuit

Yes

Output Voltage Slew Rate set by

Capacitor

Over Current Protection (OCP)

Adjustable

Over Current Protection Setting Range Channel 1

1 - 5

Over Temperature Protection (OTP)

Yes

Over Voltage Protection

Yes

Over Сurrent Protection Setting Range (A)

1 - 5

Parametric Category

Load Switches

Pkg. Dimensions (mm)

1.6 x 3.0 mm

Pkg. Type

STQFN-18

Power Good (PG), FAULT indicator

PG & FAULT

Power Monitor Output

Protection Features

CL, TSD

Published

Yes

RDSON (Typ) (mΩ)

RDSON (Typ) Channel 1 (mΩ)

Reverse current blocking

Reverse voltage detection

Short Circuit Protection

Yes

Undervoltage Protection

Yes

VIN Channel 1 max. (V)

13.2

VIN Channel 1 min. (V)

4.5

VIN Range (V)

4.5 - 13.2

VIN Range Channel 1 (V)

4.5 - 13.2

VIN max. (V)

13.2

VIN min. (V)

4.5

VOUT Discharge Circuit

Yes

VOUT Slew-rate Control

Capacitor

Products Detail

The SLG59H1127V is a high-performance, self‑powered 15mΩ NMOS load switch designed for all 4.5V to 12V power rails up to 4A. Using a proprietary MOSFET design, the SLG59H1127V achieves a stable 15mΩ RDS_ON across a wide input voltage range. Combining novel FET design and copper pillar interconnects, the SLG59H1127V package also exhibits a low thermal resistance for high‑current operation. Designed to operate over a -40 °C to 85 °C temperature range, the SLG59H1127V is available in a low thermal resistance, RoHS‑compliant, 1.6mm x 3.0mm STQFN package.

Optimized for Telecommunications Equipment, High‑performance Enterprise Computing, Motor Drives
15mΩ RDS_ON
Maximum Continuous Current: 4A
Wide Operating Supply Voltage: 4.5V to 13.2V
Automatic nFET SOA Protection
Internal 14.4V V_IN Overvoltage Protection
Capacitor-adjustable Inrush Current Control
Two-stage Current Limit Protection:
- Resistor-adjustable Active Current Limit
- Fixed 0.5A Short-circuit Current Limit
Open Drain FAULT Signaling
Open-drain Power Good (PG) Signaling
ON-OFF Control: Active HIGH
