SLG59H1401C [RENESAS]

Part No:

SLG59H1401C

Name: SLG59H1401C
Brand: RENESAS
SKU: SLG59H1401C

Category:Power Supplies

Manufacturer:RENESAS

Description:DUAL INPUT SINGLE OUTPUT, 3 A PO.OR Controller N+1 ORing Controller N-Channel 2:1 20-WLCSP (1.59x1.99)

Package:-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Pkg. Type

WLCSP-20

Lead Count (#)

Temp. Range

-40 to +85°C

Country of Assembly

Taiwan

Country of Wafer Fabrication

Taiwan

Price (USD) | 1ku

0.98025

Carrier Type

Tape & Reel

Current Monitor Output

Discharge Circuit

Enable

FET Pass Device Type

Power MUX

IDS (A)

IDS Channel 1 (A)

IDS Channel 2 (A)

Internal TVS Surge Protection

Moisture Sensitivity Level (MSL)

Output Discharge Circuit

Output Voltage Slew Rate set by

Capacitor

Over Current Protection (OCP)

Adjustable

Over Current Protection Setting Range Channel 1

1.3 - 3.5

Over Current Protection Setting Range Channel 2

1.3 - 3.5

Over Temperature Protection (OTP)

Yes

Over Voltage Protection

Yes

Over Сurrent Protection Setting Range (A)

1.3 - 3.5

Parametric Category

Load Switches

Pb (Lead) Free

Yes

Pkg. Dimensions (mm)

1.585 x 1.985 mm

Power Good (PG), FAULT indicator

Power Monitor Output

RDSON (Typ) (mΩ)

RDSON (Typ) Channel 1 (mΩ)

RDSON (Typ) Channel 2 (mΩ)

Reverse current blocking

Yes

Reverse voltage detection

Yes

Short Circuit Protection

Yes

Undervoltage Protection

Yes

VIN Channel 1 max. (V)

VIN Channel 1 min. (V)

2.8

VIN Channel 2 max. (V)

VIN Channel 2 min. (V)

2.8

VIN Range (V)

2.8 - 6

VIN Range Channel 1 (V)

2.8 - 6

VIN Range Channel 2 (V)

2.8 - 6

VIN max. (V)

VIN min. (V)

2.8

VOUT Discharge Circuit

ECCN (US)

EAR99

HTS (US)

8542.39.90

Moisture Sensitivity Level (MSL)

Pb (Lead) Free

Yes

Products Detail

The SLG59H1401C is a high voltage GreenFET Load Switch designed for OR’ing or manual Power MUX applications. The part comes with two 3 A rated load switches that are well suited for a variety of systems having multiple power sources. The device will automatically detect, select, and seamlessly transition between available inputs. Additionally, manual switching between two power rails allowed.

Two 3 A load switches with common output
Two Integrated VGS Charge Pumps
Wide operating range: 2.8 V to 6 V
Adjustable output soft start time (SS)
Low RDSON: 52 mΩ (typical)
Adjustable priority (Accuracy < ±5%)
Adjustable Overvoltage Protection (Accuracy < ±5%)
Channel status indication (ST)
Undervoltage Lockout
True Reverse-Current Blocking
Protected by thermal shutdown and adjustable current limit

Key Features

No key features available

Application scenarios

No application scenarios available
