Name: M24C08-DRMN3TP/K
Brand: STMicroelectronics
SKU: M24C08-DRMN3TP/K

Type

Parameter

Lifecycle Status

ACTIVE (Last Updated: 7 months ago)

Factory Lead Time

14 Weeks

Mounting Type

Surface Mount

Package / Case

8-SOIC (0.154, 3.90mm Width)

Surface Mount

YES

Number of Pins

Operating Temperature

-40°C~125°C TA

Packaging

Cut Tape (CT)

Series

Automotive, AEC-Q100

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Number of Terminations

ECCN Code

EAR99

Technology

CMOS

Voltage - Supply

1.7V~5.5V

Terminal Position

DUAL

Peak Reflow Temperature (Cel)

NOT SPECIFIED

Number of Functions

Supply Voltage

2.5V

Terminal Pitch

1.27mm

Time@Peak Reflow Temperature-Max (s)

NOT SPECIFIED

Base Part Number

M24C08

Supply Voltage-Max (Vsup)

5.5V

Supply Voltage-Min (Vsup)

1.7V

Interface

2-Wire, I2C, Serial

Memory Size

8Kb 1K x 8

Memory Type

Non-Volatile

Operating Mode

SYNCHRONOUS

Clock Frequency

1MHz

Access Time

450ns

Memory Format

EEPROM

Memory Interface

I2C

Memory Width

Write Cycle Time - Word, Page

4ms

Serial Bus Type

I2C

Write Cycle Time-Max (tWC)

4ms

Length

4.9mm

Height Seated (Max)

1.75mm

Width

3.9mm

RoHS Status

RoHS Compliant

M24C08-DRMN3TP/K Overview

A Non-Volatile-type memory can be classified as the memory type of this device. In addition, memory ics is available in a Cut Tape (CT) case as well. Embedded in the 8-SOIC (0.154, 3.90mm Width) case, memory ics is a single file. On the chip, there is an 8Kb 1K x 8 memory, which is the size of the chip's memory. There is a EEPROM-format memory used in this device, which is the memory format used by mainstream devices. Featuring an extended operating temperature range of -40°C~125°C TA, this device allows it to be used in a variety of demanding applications. The device is capable of handling a supply voltage of 1.7V~5.5V volts. The recommended mounting type for memory ics is Surface Mount. A total of 8 terminations have been planted on the chip. The comprehensive working procedure of this part involves 1 functions. In order to power this memory device, 2.5V will be necessary. A clock frequency rotation within 1MHz is used for the ic memory chip to rotate data. Similar parts are frequently selected using the ic memory chip's base part number, M24C08. A 8-pin package containing this memory device is used to house this device. It is an important component of the Automotive, AEC-Q100 series memory devices used in a variety of applications. Its I2C-type serial bus helps transfer data to the CPU efficiently.
