M27W401-80F6 Overview

As far as memory types are concerned, Non-Volatile is considered to be its memory type. In addition, memory ics is available in a Tube case as well. In the case of 32-CDIP (0.600, 15.24mm) Window, it is embedded within the case. A memory chip with a capacity of 4Kb 512 x 8 is used on this device. There is a mainstream memory format used by this device, which is called EPROM-format memory. This device has an extended operating temperature range of -40°C~85°C TA, so it's perfect for a wide range of demanding applications. It is capable of handling a voltage supply of 2.7V~3.6V. As far as the mounting type is concerned, Through Hole is recommended. On the chip, there are 32 terminations that are planted. The part supports at least 1 functions to ensure a comprehensive working process. In order to function properly, this ic memory chip should be powered by a voltage of 3V. In order to select similar parts, typical manufacturers refer to M27W401 as the device's base part number. The memory device has an 32-pin package, which encloses it in a small package. I have noticed that the memory device has 32 pins, which indicates that it has 32 locations in the memory. In this chip, the Through Hole mounting method is used, a straightforward, high-efficiency mounting method. In terms of its nominal supply current, this memory component has a rating of 50mA. The memory chip also offers ACCESS TIME 70 NANO SECS AT VCC 3V TO 3.6V to level up system performance despite its merits. There is only a single power supply required for this memory chip. There are I/O ports on this memory ics that have COMMON-bit memory mapping.

M27W401-80F6 Features

Package / Case: 32-CDIP (0.600, 15.24mm) Window
32 Pins
Additional Feature:ACCESS TIME 70 NANO SECS AT VCC 3V TO 3.6V
I/O Type: COMMON

M27W401-80F6 Applications

There are a lot of STMicroelectronics
M27W401-80F6 Memory applications.

• servers
• supercomputers
• telecommunications
• workstations,
• DVD disk buffer
• data buffer
• nonvolatile BIOS memory
• Camcorders
• embedded logic
• eDRAM
