Name: STW82103B
Brand: STMicroelectronics
SKU: STW82103B

STW82103B [STMicroelectronics]

Part No:

STW82103B

Wireless & RF Integrated Circuits

Manufacturer:

STMicroelectronics

Description:

General Purpose 2.3GHz~2.7GHz 1-Mixer 44-Pin 10.5dB Down Converter -40°C-Min 85°C-Max MATTE TIN 44-VFQFN Exposed Pad

Package:

-

RoHS Status:

Datasheet:

Production Status:

In Stock Status:

Specification

Type

Parameter

Lifecycle Status

NRND (Last Updated: 8 months ago)

Factory Lead Time

16 Weeks

Mounting Type

Surface Mount

Package / Case

44-VFQFN Exposed Pad

Surface Mount

YES

Number of Pins

Packaging

Tray

JESD-609 Code

Part Status

Active

Moisture Sensitivity Level (MSL)

3 (168 Hours)

Number of Terminations

ECCN Code

EAR99

Terminal Finish

MATTE TIN

Technology

BICMOS

Voltage - Supply

3V~5V

Terminal Position

QUAD

Peak Reflow Temperature (Cel)

260

Number of Functions

Supply Voltage

3.3V

Terminal Pitch

0.5mm

Frequency

2.3GHz~2.7GHz

Base Part Number

STW82103

Pin Count

Operating Temperature (Max)

85°C

Operating Temperature (Min)

-40°C

Supply Voltage-Max (Vsup)

3.45V

Temperature Grade

INDUSTRIAL

Analog IC - Other Type

PLL FREQUENCY SYNTHESIZER

Operating Supply Current

160mA

Gain

8.5dB

RF Type

General Purpose

Secondary Attributes

Down Converter

Noise Figure

10.5dB

Number of Mixers

Length

7mm

Width

7mm

Radiation Hardening

RoHS Status

RoHS Compliant

Products Detail

STW82103B Overview

A high level of reliability is provided by using an advanced RF mixer' packaging Tray.The mixer RF ships overseas conveniently packed in 44-VFQFN Exposed Pad.This RF circuit board needs to operate at 160mA supply current in order to deliver its performance.44 pins are provided on the RF mix.The RF mixer has type General Purpose RF.Try searching for STW82103 variants of the RF mixer.The mount is provided by Surface Mount.
