    OP269A [Optek]

    OP269A
    OP269A

    Part No:

    OP269A

    Category:

    LEDs

    Manufacturer:

    Optek

    Description:

    Each diode in this series is molded into an end-looking plastic package. OP168F and OP169 devices are GaAs, whereas OP268F and OP269 devices are GaAIAs.

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Continuous Forward Current
    50mA
    Fall Time OP168 169
    500 ns
    Fall Time OP268 269
    250 ns
    Forward Voltage Max OP168 169
    1.4V
    Forward Voltage Max OP268 269
    1.5V
    Lead Length OP168FA
    0.50"
    Lead Soldering Temperature
    260°C
    OP168FA EAPT Max
    0.73mW/cm²
    OP168FA EAPT Min
    0.48mW/cm²
    OP168FB EAPT Min
    0.43mW/cm²
    OP169B EAPT Max
    0.22mW/cm²
    OP169B EAPT Min
    0.11mW/cm²
    OP169C EAPT Min
    0.03mW/cm²
    OP268FA EAPT Min
    0.64mW/cm²
    OP268FB EAPT Max
    0.99mW/cm²
    OP268FB EAPT Min
    0.45mW/cm²
    OP268FC EAPT Min
    0.36mW/cm²
    OP269A EAPT Min
    0.58mW/cm²
    Operating Temperature
    -40°C ~ +100°C
    Peak Forward Current
    3.0A
    Power Dissipation
    100mW
    Reverse Current
    100µA
    Reverse Voltage
    2.0V
    Rise Time OP168 169
    1000 ns
    Rise Time OP268 269
    500 ns
    Total Beam Angle OP168FA
    104°
    Total Beam Angle OP169B
    18°
    Total Beam Angle OP268FA
    104°
    Total Beam Angle OP269A
    18°
    Wavelength Peak OP168 169
    935 nm
    Wavelength Peak OP268 269
    890 nm

    Products Detail

    The series includes infrared emitters with flat lens (OP168, OP268) for wide radiation angle and integral lens (OP169, OP269) for narrow beam angle. They are easily stackable on 0.100" (2.54 mm) hole centers and mechanically/spectrally matched to other OPTEK devices. The black package is for OP168F and OP268F, clear for OP169 and OP269. Due to small size, they offer design flexibility for space-limited applications.

    Key Features

    • Flat lens for wide radiation angle (OP168, OP268)
    • Integral lens for narrow beam angle (OP169, OP269)
    • Easily stackable on 0.100" (2.54 mm) hole centers
    • Mechanically and spectrally matched to other OPTEK devices

    Application scenarios

    • Space-limited applications
    • PCBoard mounted slotted switch
    • PCBoard interrupter

    Documents

    Datasheets:

    OP168F,169,268F,269 Series
    Product FAQ

    1. Is OP269A available for RFQ?

    Yes. OP269A by Optek is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for OP269A?

    Pricing for OP269A can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of OP269A?

    OP269A is a Optek LEDs with Forward Voltage Max OP168 169: 1.4V and Forward Voltage Max OP268 269: 1.5V. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for OP269A?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can OP269A be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to OP269A?

    Yes. If OP269A is unavailable, obsolete, or does not meet your required lead time, we can help check similar Optek LEDs parts or compatible alternatives.
