    PB63DP [Apex Microtechnology]

    PB63DP
    PB63DP

    Part No:

    PB63DP

    Category:

    Amplifier ICs

    Manufacturer:

    Apex Microtechnology

    Description:

    The PB63 is a dual high voltage, high current booster amplifier designed to provide voltage and current gain for a small signal, general purpose op amp.

    Datasheet:

    Product FAQ

    1. Is PB63DP available for RFQ?

    Yes. PB63DP by Apex Microtechnology is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for PB63DP?

    Pricing for PB63DP can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of PB63DP?

    PB63DP is a Apex Microtechnology Amplifier ICs with Continuous Output Current: 2A and Operating Temperature: -25°C ~ +85°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for PB63DP?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can PB63DP be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to PB63DP?

    Yes. If PB63DP is unavailable, obsolete, or does not meet your required lead time, we can help check similar Apex Microtechnology Amplifier ICs parts or compatible alternatives.

    RFQ

    Part Number:

    PB63DP

    Manufacturer:

    Apex Microtechnology

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    Continuous Output Current
    2A
    Operating Temperature
    -25°C ~ +85°C
    Package
    12-pin power SIP
    Quiescent Current
    37mA
    Supply Voltage
    ±20V ~ ±75V

    Products Detail

    The PB63 is a dual high voltage, high current booster amplifier designed to provide voltage and current gain for a small signal, general purpose op amp. It features complementary MOSFET output stage for symmetrical output impedance and eliminates second breakdown limitations. The hybrid circuit uses Beryllia (BeO) substrate, thick film resistors, ceramic capacitors, and semiconductor chips for reliability and performance. It is packaged in a 12-pin power SIP with electrically isolated case.

    Key Features

    • Wide Supply Range: ±20 V to ±75 V
    • High Output Current: Up to 2 A Continuous
    • Programmable Gain
    • High Slew Rate: 1000 V/µs Typical
    • Programmable Output Current Limit
    • High Power Bandwidth: 1 MHz Typical
    • Low Quiescent Current: 37 mA Typical (Total, Both Channels)

    Application scenarios

    • LED Test Equipment
    • LCD Test Equipment
    • Semiconductor Test Equipment
    • High Voltage Instrumentation
    • Electrostatic Transducers and Deflection
    • Piezoelectric Positioning and Actuation
    • Programmable Power Supplies

    Documents

    Datasheets:

    PB63 Datasheet12-Power SIP Drawing
