STEVAL-MKIT04KA [STMicroelectronics]

The STEVAL-MKIT04KA is composed by four different adapters DIL24: the STEVAL-MKI224V1, the STEVAL-MKI227A contained in the STEVAL-MKI227KA adapter kit, the STEVAL-MKI235A contained in the STEVAL-MKI235KA adapter kit, the STEVAL-MKE003A contained in the STEVAL-MKI227KA and STEVAL-MKI235KA adapter kit.

All SMD devices are soldered on the boards. Male and female connectors must be manually soldered.

The STEVAL-MKE003A can be plugged over the STEVAL-MKI227A or the STEVAL-MKI235A board.

In case the application using LSM6DSV16X is fixed it is possible to solder a 0 ohm resistor instead of shunt in the JQ connector.

These adapters are singularly supported by the STEVAL-MKI109V3 motherboards, which includes a high performance 32-bit microcontroller functioning as a bridge between the sensor and a PC.

On the STEVAL-MKI109V3 it is possible to use the downloadable graphical user interface (Unico-GUI or MEMS-Studio), or dedicated software routines for customized applications.

It is also possible to plug the single board into X-NUCLEO-IKS01A3.

• User friendly LSM6DSV16X, LIS2DUXS12, LPS22DF board
• Complete LSM6DSV16X, LIS2DUXS12, LPS22DF pinout for a standard DIL 24 sockets
• Fully compatible with the STEVAL-MKI109V3 motherboard
• RoHS compliant
