PDB-C142 [Advanced Photonix]

Name: PDB-C142
Brand: Advanced Photonix
SKU: PDB-C142
Availability: InStock

Part No:

PDB-C142

Category:

Optical Detectors & Sensors

Manufacturer:

Advanced Photonix

Description:

Through Hole -40°C~80°C Bulk Wavelength: 660nm Radial, 5mm Dia (T 1 3/4) 100V 4.12mm2 5nA

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Factory Lead Time

14 Weeks

Mount

Through Hole

Mounting Type

Through Hole

Package / Case

Radial, 5mm Dia (T 1 3/4)

Housing Material

Plastic

Operating Temperature

-40°C~80°C

Packaging

Bulk

Published

2005

Part Status

Active

Moisture Sensitivity Level (MSL)

1 (Unlimited)

Lead Length

26.5mm

Diode Type

Viewing Angle

40°

Voltage - DC Reverse (Vr) (Max)

100V

Breakdown Voltage

25V

Rise Time

50ns

Max Reverse Voltage (DC)

100V

Wavelength

660nm

Dark Current

5nA

Spectral Range

400nm ~ 1100nm

Active Area

4.12mm2

Color - Enhanced

Blue

Diameter

5.6mm

Height

8.7mm

RoHS Status

RoHS Compliant

Lead Free

Products Detail

PDB-C142 Overview

To protect the photodiodes, they are packed in the Bulk. Photodiodes are protected by Radial, 5mm Dia (T 1 3/4) packages in order to ensure their safety. When reverse-bias is applied continuously, the photodiodes are able to withstand only 100V voltage. A reverse-bias photodiode shouldn't exceed 100V continuously in reverse-bias mode. Ensure photodiodes work by setting the breakdown voltage to 25V. A photodiode occurs even at 5nA current without light input.

PDB-C142 Features

Moisture Sensitivity Level (MSL): 1 (Unlimited)
Operating Temperature: -40°C~80°C
Packaging: Bulk
Diode Type: PIN
Mount: Through Hole
Spectral Range: 400nm ~ 1100nm
Viewing Angle: 40°

PDB-C142 Applications

There are a lot of Advanced Photonix
PDB-C142 Photodiodes applications.

Light Barriers
Vision Controls
Measurement Levelling
High speed photo detectors
Health Monitoring
Heart Rate Monitoring
Pulse Oximetry
Pure UV-C Monitoring
Sterilization Lamp Monitoring
Optical Analytics

Documents

Datasheets:

PDB-C142 Datasheet PDB-C142-Advanced-Photonix-datasheet-143348.pdf

Product FAQ

1. Is PDB-C142 available for RFQ?

Yes. PDB-C142 by Advanced Photonix is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for PDB-C142?

Pricing for PDB-C142 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of PDB-C142?

PDB-C142 is a Advanced Photonix Optical Detectors & Sensors with Packaging: Bulk and Moisture Sensitivity Level (MSL): 1 (Unlimited) and Voltage - DC Reverse (Vr) (Max): 100V. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for PDB-C142?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can PDB-C142 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to PDB-C142?

Yes. If PDB-C142 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Advanced Photonix Optical Detectors & Sensors parts or compatible alternatives.
