    EVB-USB2660 [Microchip]

    EVB-USB2660
    EVB-USB2660

    Part No:

    EVB-USB2660

    Category:

    Other Modules

    Manufacturer:

    Microchip

    Description:

    The SMSC USB2660/USB2660i is a USB 2.0 compliant, Hi-Speed hub, card reader, and protocol converter combo solution.

    RoHS Status:

    Product FAQ

    1. Is EVB-USB2660 available for RFQ?

    Yes. EVB-USB2660 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for EVB-USB2660?

    Pricing for EVB-USB2660 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of EVB-USB2660?

    EVB-USB2660 is a Microchip Other Modules with USB2660i Operating Temperature Max: +85°C and USB2660i Operating Temperature Min: -40°C. Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for EVB-USB2660?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can EVB-USB2660 be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to EVB-USB2660?

    Yes. If EVB-USB2660 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Other Modules parts or compatible alternatives.

    RFQ

    Part Number:

    EVB-USB2660

    Manufacturer:

    Microchip

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    BEST SELL
    89H16NT16G2ZCHLG

    89H16NT16G2ZCHLG

    RENESAS

    BEST SELL
    TMS5700432APZQQ1

    TMS5700432APZQQ1

    Texas Instruments

    BEST SELL
    TMS320F28035PAGS

    TMS320F28035PAGS

    Texas Instruments

    BEST SELL
    K4AAG165WA-BCWE

    K4AAG165WA-BCWE

    SAMSUNG

    BEST SELL
    MPU-6000EVB

    MPU-6000EVB

    TDK

    BEST SELL
    H9TQ26ADFTACUR-KUM

    H9TQ26ADFTACUR-KUM

    SK HYNIX

    BEST SELL
    KHBB84A03B-MC1J

    KHBB84A03B-MC1J

    SAMSUNG

    BEST SELL
    MT48LC16M16A2P-6A IT:G

    MT48LC16M16A2P-6A IT:G

    Micron

    BEST SELL
    ISL8200MIRZ-T

    ISL8200MIRZ-T

    RENESAS

    BEST SELL
    PMEG4010CEGW-QJ

    PMEG4010CEGW-QJ

    NEXPERIA

    Related Information
    Similar Products
    Related Products
    Related Categories
    Recently Viewed
    • Part Number
      Manufacturer
      Stock Status
      Pricing
      RoHS/Datasheet
    • SAFETY-PKG-MPF-MPFS-NL
      Microchip
      Available for RFQ
      Request Volume Pricing
      -
    • PG164110
      Microchip
      Available for RFQ
      Request Volume Pricing
    • DV164133
      Microchip
      Available for RFQ
      Request Volume Pricing
    • TWIZ5200
      Microchip
      Available for RFQ
      Request Volume Pricing
    • PG164100
      Microchip
      Available for RFQ
      Request Volume Pricing
    • KSZ9031MNX-EVAL
      Microchip
      Available for RFQ
      Request Volume Pricing
    • ATPL00BDK-99
      Microchip
      Available for RFQ
      Request Volume Pricing
    • MIC37122YMT-EV
      Microchip
      Available for RFQ
      Request Volume Pricing
    • KSZ9021GN-EVAL
      Microchip
      Available for RFQ
      Request Volume Pricing
      -
    • PD-IM-7548H
      Microchip
      Available for RFQ
      Request Volume Pricing

    LX7730-DB

    LX7730-DB

    Microchip

    AT89RFD-02

    AT89RFD-02

    Microchip

    ADM00974

    ADM00974

    Microchip

    KSZ8091RNB-EVAL

    KSZ8091RNB-EVAL

    Microchip

    EVB-USB2514BC

    EVB-USB2514BC

    Microchip

    ATMXT2912TDAT-SPI-PCB

    ATMXT2912TDAT-SPI-PCB

    Microchip

    DS3105DK

    DS3105DK

    Microchip

    AT98SC-STK01-032R

    AT98SC-STK01-032R

    Microchip

    ATPANCOORDINATOR-EK

    ATPANCOORDINATOR-EK

    Microchip

    ATSAME70-XPLD

    ATSAME70-XPLD

    Microchip

    Computing(22030)Ethernet & Communication Modules(10157)Wireless & RF Modules(1080)Sensor Modules(152)Accelerator Cards(8)Power Management Modules(17522)Audio Modules(227)Video Modules(303)Software(259)Memory & Data Storage(446)

    No recently viewed products

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    TypeParameter
    Ram
    9 KB
    Supply Voltage
    3.3V
    Package
    64-pin QFN (9x9 mm)
    RoHS Status
    RoHS Compliant
    RoHS Status
    RoHS Compliant
    Core
    8051
    Core Frequency
    60MHz
    Core Voltage
    1.8V
    Gpio
    up to 20
    Halogen Free
    Yes
    Max Sustained Transfer Rate
    35 MB/s
    Ordering Info
    USB2660/USB2660i-JZX
    Oscillator
    24MHz
    Rom
    64 KB
    USB2660 Operating Temperature Max
    +70°C
    USB2660 Operating Temperature Min
    0°C
    USB2660i Operating Temperature Max
    +85°C
    USB2660i Operating Temperature Min
    -40°C

    Products Detail

    This fully integrated single chip solution provides USB expansion and flash card media reader/writer integration. It supports multiple flash media formats including SD, MMC, Memory Stick, and xD-Picture Card. The controller features two exposed Hi-Speed USB 2.0 downstream ports for external peripheral expansion, with an internal third port dedicated to flash media reading/writing as a USB Compound Device. It includes programmable features like PortMap for flexible port mapping, PortSwap for USB differential-pair pin alignment, and PHYBoost for signal integrity recovery. The device contains an 8051 microprocessor, 9 KB RAM, 64 KB ROM, and up to 20 configurable GPIOs. It operates from a single 3.3V external supply with internal 1.8V core regulation.

    Key Features

    • Single chip hub and flash media controller combo
    • USB 2.0 Hi-Speed compliance
    • Supports SD 2.0, MMC 4.2, MS 1.43, MS-Pro 1.02, MS-Pro-HG 1.01, MS-Duo 1.10, xD 1.2
    • Two exposed Hi-Speed USB 2.0 downstream ports
    • Internal flash media reader attached to third downstream port
    • Transaction translator (TT) for Full-Speed/Low-Speed peripherals
    • Full power management (individual/ganged)
    • External firmware access via SPI/I2C ROM
    • Onboard 24 MHz crystal driver
    • Optional external 24 MHz clock input
    • Up to 20 configurable GPIOs (2 with 200mA drive)
    • 8051 8-bit microprocessor at 60 MHz
    • Integrated 1.8V core regulator
    • Programmable PortMap, PortSwap, PHYBoost
    • Customizable vendor/product IDs via external ROM
    • Commercial (USB2660) and industrial (USB2660i) temperature ranges
    • 64-pin QFN package
    • RoHS compliant.

    Application scenarios

    • Desktop and mobile PCs
    • Printers
    • GPS navigation systems
    • Media players/viewers
    • Consumer A/V
    • Set-top boxes
    • Industrial products

    Documents

    Datasheets:

    USB2660/iEVB-USB2660/i Eval Brd Manual
