EVB-USB3740 [Microchip]

Name: EVB-USB3740
Brand: Microchip
SKU: EVB-USB3740
Availability: InStock

Part No:

EVB-USB3740

Other Modules

Manufacturer:

Microchip

Description:

The USB3740B is a USB 2.0 compliant High Speed switch that provides robust ESD protection to the interface in an extremely small package.

RoHS Status:

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

ESD Hbm

8000V

Supply Voltage

3.0V ~ 5.5V

Operating Temperature

-40°C ~ +85°C

Package

QFN (1.3x1.8x0.55mm, 0.4mm pitch) and QFN (1.6x2.1x0.55mm, 0.5mm pitch)

RoHS Status

RoHS Compliant

Active Standby Current Max

175nA

Active Standby Current Typ

30nA

Bandwidth Max

1100MHz

Bandwidth Min

950MHz

Input Logic High Threshold

1.4V

Input Logic Low Threshold

0.4V

Products Detail

High Speed USB 2.0 Switch with ESD Protection and Low Standby Current. Features a high bandwidth USB mux for multiplexing USB lanes between different functions, integrated ESD protection (8kV HBM) eliminating external components, extremely low power design (30nA active/standby current) ideal for battery applications, and control inputs accommodating 1.8V to 5V with DP/DM tolerance up to 5.5V. Available in RoHS compliant QFN packages with automotive option.

Key Features

High Speed USB Mux
Up to 1GHz Bandwidth
USB Port ESD Protection (8kV HBM)
Low Standby Current (30nA)
Extremely low power design for battery applications
Control inputs accommodate 1.8V to 5V
DP/DM tolerate up to 5.5V
Operating Temperature -40°C to +85°C
RoHS compliant QFN package
Automotive option

Documents

Datasheets:

USB3740 Datasheet

Product FAQ

1. Is EVB-USB3740 available for RFQ?

Yes. EVB-USB3740 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

2. Why is there no fixed price for EVB-USB3740?

Pricing for EVB-USB3740 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

3. What are the key specifications of EVB-USB3740?

EVB-USB3740 is a Microchip Other Modules with Active Standby Current Max: 175nA and Active Standby Current Typ: 30nA. Review the product details or submit an RFQ if you need confirmation before purchase.

4. How fast can I get a quote for EVB-USB3740?

Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

5. How soon can EVB-USB3740 be shipped?

If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

6. Can you suggest alternatives to EVB-USB3740?

Yes. If EVB-USB3740 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Other Modules parts or compatible alternatives.
