    EVB9514 [Microchip]

    EVB9514
    EVB9514

    Part No:

    EVB9514

    Category:

    Other Modules

    Manufacturer:

    Microchip

    Description:

    The LAN9514 is a high performance, Hi-Speed USB 2.0 hub with a 10/100 Ethernet controller. The EVB9514 is an Evaluation Board that utilizes the LAN9514 to provide a four port USB 2.0 hub with an integrated 10/100 Ethernet controller.

    RoHS Status:

    Product FAQ

    1. Is EVB9514 available for RFQ?

    Yes. EVB9514 by Microchip is available for RFQ. Submit your required quantity and our team will confirm real-time stock, lead time, and volume pricing.

    2. Why is there no fixed price for EVB9514?

    Pricing for EVB9514 can vary by order quantity, market availability, date code, packaging, and delivery destination. Request a quote to receive the latest volume pricing.

    3. What are the key specifications of EVB9514?

    EVB9514 is a Microchip Other Modules with Ethernet Connector: RJ-45 with integrated magnetics and Usb Downstream: 4x Type A (FCI 87520-0010BLF). Review the product details or submit an RFQ if you need confirmation before purchase.

    4. How fast can I get a quote for EVB9514?

    Our sales team usually responds within 24 hours after receiving your RFQ. The quote may include stock status, unit price, lead time, shipping options, and available alternatives.

    5. How soon can EVB9514 be shipped?

    If stock is confirmed, in-stock parts can usually ship within 1–2 business days. Final lead time depends on quantity, stock source, and delivery destination.

    6. Can you suggest alternatives to EVB9514?

    Yes. If EVB9514 is unavailable, obsolete, or does not meet your required lead time, we can help check similar Microchip Other Modules parts or compatible alternatives.

    RFQ

    Part Number:

    EVB9514

    Manufacturer:

    Microchip

    Looking for Pricing? Contact us for volume pricing.

    IMPORTANT NOTICE

    Quotations are subject to stock availability and may vary with market conditions. Prices and lead times are not guaranteed until a purchase order is confirmed. Ensure your contact details are correct to avoid delays in response.

    Featured Product

    Datasheet:

    Stock Status:

    Available for RFQ

    Pricing:

    Request Volume Pricing

    Quote Response:

    Within 24 Hours

    Shipping:

    In-stock parts ship in 1–2 business days

    Specification

    Type
    Parameter
    RoHS Status
    Non-RoHS Compliant
    RoHS Status
    RoHS Compliant
    Eeprom
    512x8 Microwire
    Ethernet Connector
    RJ-45 with integrated magnetics
    Fuse
    3A
    Gpio Header
    10-pin
    Jtag Header
    6-pin
    Power Input
    +5V DC, barrel plug 2.0mm center positive
    Power Supply
    bus-powered or self-powered
    Usb Downstream
    4x Type A (FCI 87520-0010BLF)
    Usb Upstream
    1x Type B (AMP 292304-1)

    Products Detail

    The LAN9514 contains an integrated USB 2.0 hub, four integrated downstream USB 2.0 PHYs, an integrated upstream USB 2.0 PHY, a 10/100 Ethernet PHY, a 10/100 Ethernet controller, a TAP controller, and an EEPROM controller. The EVB9514 provides USB connectivity via one type B upstream USB connector and four type A downstream USB connectors. An RJ-45 integrated magnetics Ethernet jack with link/activity LEDs provides 10/100 Ethernet connectivity. The EVB9514 supports both bus-powered and self-powered modes of operation. The board includes a 512x8 Microwire EEPROM for automatic loading of USB descriptors, USB device configuration, and the MAC address upon reset. A GPIO header provides access to the LAN9514’s general purpose I/O signals, and a JTAG header is included for debugging.

    Key Features

    • Hi-Speed USB 2.0 hub
    • 10/100 Ethernet controller
    • Integrated USB 2.0 PHYs (1 upstream, 4 downstream)
    • Integrated 10/100 Ethernet PHY
    • TAP controller
    • EEPROM controller
    • 512x8 Microwire EEPROM
    • GPIO header
    • JTAG header
    • Supports bus-powered and self-powered modes
    • RJ-45 Ethernet jack with link/activity LEDs
    • USB Type B upstream connector
    • Four USB Type A downstream connectors.
