M34C02-WDW6T Overview

In terms of its memory type, it can be classified as Non-Volatile. The case comes in Tape & Reel (TR) size. The case is embedded in 8-TSSOP (0.173, 4.40mm Width). Memory size on the chip is 2Kb 256 x 8. This device uses takes advantage of the EEPROM format. The device's extended operating temperature range of -40°C~85°C TA makes it ideal for many demanding applications. The device is capable of handling a supply voltage of 2.5V~5.5V. The recommended mounting type for this device is Surface Mount. On the chip, there are 8 terminations. The comprehensive working procedure is supported by 1 functions in this part. A voltage of 5V is required for the operation of this memory device. There is a clock frequency rotation of the memory within a 400kHz range. It is common to select similar parts by referring to the device's base part number, M34C02. An 8-pin package is used to package this memory device. A memory device like this has 8 pins, indicating that there are 8 memory locations on the device. This memory chip requires only 3/5V of power. By integrating this memory with a I2C-type serial bus, data can be carried and transferred to the CPU easily. With a maximum supply current of 0.002mA , it is able to operate from a variety of supplies.

M34C02-WDW6T Features

Package / Case: 8-TSSOP (0.173, 4.40mm Width)
8 Pins

M34C02-WDW6T Applications

There are a lot of STMicroelectronics
M34C02-WDW6T Memory applications.

• eSRAM
• mainframes
• multimedia computers
• networking
• personal computers
• servers
• supercomputers
• telecommunications
• workstations,
• DVD disk buffer
