SATEL-VL53L4ED [STMicroelectronics]

The SATEL-VL53L4ED package includes two breakout boards, which can be easily integrated into the customer's devices.

The PCB section that embeds the VL53L4ED module is perforated. The developers can then break off the mini-PCB and use it in a 3.3 V supply application via flying wires.

This makes it easier to integrate the SATEL-VL53L4ED breakout boards into the development and evaluation devices thanks to their small size.

Note that the evaluation boards shall be tested exclusively under normal temperature conditions, the SATEL-VL53L4ED board is not rated for high temperature operation.

• VL53L4ED Time-of-Flight high accuracy proximity sensor with extended temperature capability
• High-performance proximity ranging, independent of the target size and reflectance
• From 0 to 1300 mm with full field of view (FoW)
• Effective sensor temperature range of -40°C to 105°C
• Up to 400 mm ranging under 100 klux
• Short distance linearity down to 1 mm
• Divisible board that can be used as a mini-PCB breakout board, easy to integrate into the customer's device
• Two breakout boards available in the package
• Compatible with X-NUCLEO-53L4A3
