MDL-IDM-B [Texas Instruments]

Name: MDL-IDM-B
Brand: Texas Instruments
SKU: MDL-IDM-B
Availability: InStock

Part No:

MDL-IDM-B

Category:

Computing

Manufacturer:

Texas Instruments

Description:

Stellaris® Intelligent Display Modules (MDL-IDM and MDL-IDM28) offer a complete graphical touch-screen user interface solution for control, automation, and instrumentation applications.

Datasheet:

Stock Status:

Available for RFQ

Pricing:

Request Volume Pricing

Quote Response:

Within 24 Hours

Shipping:

In-stock parts ship in 1–2 business days

Specification

Type

Parameter

Operating Temperature

-20°C ~ +50°C

Storage Temperature

-30°C ~ +70°C

Analog Input Limit Max

3.3V

Analog Input Limit Min

-0.3V

Analog Input Voltage Max

3V

Analog Input Voltage Min

0V

Analog Inputs

4

Brightness Min

210 Cd/m2

Brightness Typ

220 Cd/m2

Core

ARM Cortex-M3

Display Backlight

White LED

Display Color Depth

16-bit

Display Resolution

240x320

Display Size

2.8 inch

Ethernet

10/100

Ethernet Features

Auto MDI/MDIX, Link/Activity LED

Flash

256 KB

Frequency

50MHz

Image Ram

168 KB

MDL-IDM Auxiliary Output Current Max

100mA

MDL-IDM Auxiliary Output Voltage Max

5.25V

MDL-IDM Auxiliary Output Voltage Min

4.75V

MDL-IDM Dc Jack Supply Current

42mA

MDL-IDM Dc Jack Supply Voltage Max

55V

MDL-IDM Dc Jack Supply Voltage Min

20V

MDL-IDM Packing

Single-Unit Packaging

MDL-IDM Poe Isolation Voltage Max

250V

MDL-IDM Poe Supply Current

21mA

MDL-IDM Poe Supply Voltage Max

55V

MDL-IDM Poe Supply Voltage Min

38V

MDL-IDM-B Packing

Volume Packaging

MDL-IDM28 Packing

Single-Unit Packaging

MDL-IDM28-B Packing

Volume Packaging

Microcontroller

LM3S6918

Microsd Slot

Yes (typically 1 GB)

Poe Compliance

IEEE 802.3af

Relay Contact Current Max

250mA

Relay Contact Voltage Max

60V

Relay Output

1 (SPDT)

Rs232 Data Rate Max

120 Kbps

Rs232 Input Threshold High Max

2.4

Rs232 Input Threshold High Typ

1.5

Rs232 Input Threshold Low Min

0.6

Rs232 Input Threshold Low Typ

1.2

Rs232 Transmitter Voltage Swing Min

±5.0V

Rs232 Transmitter Voltage Swing Typ

±5.4V

Serial

RS232

Serial Default

115.2k,8,n,1

Sram

64 KB

Terminal Block Supply Current

200mA

Terminal Block Supply Current Max

300mA

Terminal Block Supply Voltage Max

5.5V

Terminal Block Supply Voltage Min

4.5V

Touch Panel

4-wire resistive

View Angle H Max

+45 deg

View Angle H Min

-45 deg

View Angle V Max

+35 deg

View Angle V Min

-10 deg

Products Detail

The Stellaris® Intelligent Display Modules (MDL-IDM and MDL-IDM28) are based on the LM3S6918 microcontroller (32-bit ARM Cortex-M3, 50 MHz). They feature a 2.8" QVGA LCD (240x320, 16-bit color, resistive touch) and 10/100 Ethernet. The MDL-IDM includes Power over Ethernet (PoE) and a 24V DC jack, while the MDL-IDM28 lacks PoE. Both have 5V DC terminals, serial (RS232), 4 analog inputs, and a relay output. Memory includes 256 KB flash, 64 KB SRAM, 168 KB image RAM, and a microSD slot. Software development is supported by the Stellaris Graphics Library and various tools.

Key Features

2.8" QVGA LCD (240x320, 16-bit, resistive touch)
10/100 Ethernet (Auto MDI/MDIX)
RS232 serial
Stellaris LM3S6918 (ARM Cortex-M3, 50 MHz)
256 KB flash, 64 KB SRAM, 168 KB image RAM, microSD slot
Power: PoE (IEEE 802.3af), 24V DC jack (PoE modules), 5V DC terminals
Peripherals: 4x analog inputs, 1x relay output
Software: example apps, Stellaris Graphics Library, supports multiple development tools

Application scenarios

Industrial control
automation
instrumentation
embedded web server
